Specifications
temper glass stove1.full automatic system
2.double direction
3.57 years experience
4.Certification: CE, ISO etc
2% flatness Size Customized intelligent control flat tempered glass stove
1.Brife introduction of temper glass stove
This glass bending &tempering furnace is used for producing large-size flat, bent tempered glass for architecture, and multi-curvature bent tempered glass for automobile, shower cabins and kitchen, etc.
2.Picture of temper glass stove
3.Technical parameter of temper glass stove
type | Max. size(mm) | Min. size(mm) | Thickness(mm) | Capacity(m2/h) | Power supply capacity(KVA) |
HP1506 | 1500*600 | 90*90 | 3-8 | 14 | ≥100 |
HP1508 | 1500*800 | 100*100 | 3-12 | 18 | ≥150 |
HP2010 | 2000*1000 | 100*100 | 3-12 | 30 | ≥200 |
HP2012 | 2000*1200 | 120*120 | 3-12 | 37 | ≥250 |
HP2512 | 2500*1200 | 120*120 | 3-12 | 46 | ≥250 |
HP2515 | 2500*1500 | 150*250 | 3-19 | 57 | ≥315 |
HP3015 | 3000*1500 | 150*250 | 3-19 | 69 | ≥400 |
HP2518 | 2500*1800 | 150*250 | 3-19 | 69 | ≥400 |
HP3018 | 3000*1800 | 150*250 | 3-19 | 83 | ≥400 |
HP3618 | 3660*1800 | 150*250 | 3-19 | 99 | ≥500 |
HP3021 | 3000*2100 | 150*250 | 4-19 | 96 | ≥500 |
HP3621 | 3660*2100 | 150*250 | 4-19 | 116 | ≥600 |
HP4221 | 4200*2100 | 150*250 | 4-19 | 135 | ≥700 |
HP3624 | 3660*2440 | 150*250 | 4-19 | 132 | ≥630 |
HP4224 | 4200*2440 | 150*250 | 4-19 | 154 | ≥800 |
HP5024 | 5000*2440 | 150*250 | 4-19 | 184 | ≥1000 |
HP6024 | 6000*2440 | 150*250 | 5-22 | 220 | ≥1000 |
HP5028 | 5000*2800 | 200*300 | 5-22 | 214 | ≥1000 |
HP6028 | 6000*2800 | 200*300 | 5-22 | 257 | ≥1250 |
4.Processable glass
1) Clear float glass
2) Reflective glass
3) Low-E glass
4) Patterned glass
5) color float glass
6) single face silk screen glass
7) super white pattern glass
5.Electric parts configuration
Electric parts | brand |
Electrical system | Omron(Japan),Siemens(Optional) |
Ceramic rollers | Zhongcai(China famous brand), VSV(Optional) |
Insulated cotton | Luyang(China), ISOLITE(Optional) |
Heating wire | Cr15Ni60 |
motor | Made in china, ABB(Optional) |
Frequency inverter | Schneider(France),CONVO(Germany),Mitsubishi(Optional) |
6.Packing and shipping
7.Our factury
8. ourservice
1). Free home installment and technical training, and guiding you how to operate it.
2). Offering operation parameter for processing different laminated glasses, such as tempered glass, float glass, real flower glass and picture laminated glass, etc.
9 Contact:
