Home > Manufacturing & Processing Machinery > Glass Machine > Glass Production Line > CE Approved Global Training China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace

CE Approved Global Training China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace

Name: CE Approved Global Training China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace
Brand: HUAXING
SKU: 141834546
Availability: InStock

CE Approved Global Training China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace thumbnail-1

CE Approved Global Training China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace photo-1

US$ 300,000 - 570,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Machine Type:

Glass Tempering Furnace

Production Capacity:

15-18 loads/h

Contact Supplier Request Quote Chat Now

China Glass Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port Tianjin Port Shanghai Port China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Machine Type Glass Tempering Furnace

Production Capacity 15-18 loads/h

Place of Origin Shandong, China

Brand Name HUAXING

Model Number Mini Glass Tempering Furnace

Voltage 3 phases, 380v, 50Hz or as per your requirements

Power(W) 792000

Dimension(L*W*H) 7000*4000*2000mm

Weight about 3220kg

Certification Other, CE,ISO etc

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Full automatic
2. Double exhaust fan
3. Beckhoff intelligent control
4 Convection and radiation heating
5.CE, ISO etc

CE approved China Manufacturing Electric Flat/Bent Mini Glass Tempering Furnace

1. Brief introduction of Mini Glass Tempering Furnace

Mini glass tempering furnace is used for producing large-size flat, bent tempered glass for architecture, and multi-curvature bent tempered glass for automobile, shower cabins and kitchen, etc. The type of sheet glass can be various such as float glass, coated glass, tinted glass,soft low-E glass etc.

2. Mini glass tempering furnace picture

3. Technical parameter (for your refference)

Type	Max. size(mm)	Min. size(mm)	Thickness(mm)	Capacity(m²/h)	Power supply capacity(KVA)
HP1506	1500*600	90*90	3-8	14	≥100
HP1508	1500*800	100*100	3-12	18	≥150
HP2010	2000*1000	100*100	3-12	30	≥200
HP2012	2000*1200	120*120	3-12	37	≥250
HP2512	2500*1200	120*120	3-12	46	≥250
HP2515	2500*1500	150*250	3-19	57	≥315
HP3015	3000*1500	150*250	3-19	69	≥400
HP2518	2500*1800	150*250	3-19	69	≥400
HP3018	3000*1800	150*250	3-19	83	≥400
HP3618	3660*1800	150*250	3-19	99	≥500
HP3021	3000*2100	150*250	4-19	96	≥500
HP3621	3660*2100	150*250	4-19	116	≥600
HP4221	4200*2100	150*250	4-19	135	≥700
HP3624	3660*2440	150*250	4-19	132	≥630
HP4224	4200*2440	150*250	4-19	154	≥800
HP5024	5000*2440	150*250	4-19	184	≥1000
HP6024	6000*2440	150*250	5-22	220	≥1000
HP5028	5000*2800	200*300	5-22	214	≥1000
HP6028	6000*2800	200*300	5-22	257	≥1250

4. Tempered glass application area

1) Laminated tempered glass: Architectural glass, tempered glass, bending glass, bullet-proof glass, art glass sandwiched with true flower, silk, cloth, pattern, photo etc.

2) Windshield for cars, trains, military vehicles and ships

3) Solar pv panel/led laminated glass

5. Technical features of Mini Glass Tempering Furnace

1). Adopting Jet Convection heating technology and have a flat quenching section and a bending quenching section

2) Each bending system has one individual fine adjusting device, slightly adjusting the local curve necessarily for the best possible quality products.
3). Adopting precise screw pairs in bending mechanism, which ensures smooth curve of bent glass. There will be no accumulated error in bending mechanism.
4) Different curves can be achieved by simply input the numbers via human-machine interface. With precise screw pairs in bending mechanism and servo control system, the end products are of high quality.

6.Electric parts configuration

Electric parts	brand
Electrical system	Omron(Japan),Siemens(Optional)
Ceramic rollers	Zhongcai(China famous brand), VSV(Optional)
Insulated cotton	Luyang(China), ISOLITE(Optional)
Heating wire	Cr₁₅Ni₆₀
Motor	Made in china, ABB(Optional)
Frequency inverter	Schneider(France),CONVO(Germany),Mitsubishi(Optional)

7.Packing and shipping

1) wrapped by plastic film

2) according to customers' requirement

8. Factory Picture

China Glass Tech Co., Ltd is specialized in the research, manufacturing and marketing of various kinds of glass and glass machinery, mainly including tempering furnace and tempered glass, insulated glass, laminated glass etc.
