Specifications
1. Full automatic tempering furnace2. Flat/bent tempering
3. Convection/radiation heating
4. Manufacture
5.CE, ISO standard
CE Certification automatic Force Convection Flat/Curved tempered glass stove
1. Brief Introduction
Tempering machine is used for producing large-size flat,tempered glass for architecture, and multi-curvature tempered glass for automobile, shower cabins and kitchen, etc. The type of sheet glass can be various such as float glass, coated glass, tinted glass,soft low-E glass etc.
2. Picture of glass stove
3. Technical parameter
Type | Max. size(mm) | Min. size(mm) | Thickness(mm) | Capacity(m2/h) | Power supply capacity(KVA) |
HP1506 | 1500*600 | 90*90 | 3-8 | 14 | not low than100 |
HP1508 | 1500*800 | 100*100 | 3-12 | 18 | not low than150 |
HP2010 | 2000*1000 | 100*100 | 3-12 | 30 | not low than 200 |
HP2012 | 2000*1200 | 120*120 | 3-12 | 37 | not low than 250 |
HP2512 | 2500*1200 | 120*120 | 3-12 | 46 | not low than 250 |
HP2515 | 2500*1500 | 150*250 | 3-19 | 57 | not low than 315 |
HP3015 | 3000*1500 | 150*250 | 3-19 | 69 | not low than 400 |
HP2518 | 2500*1800 | 150*250 | 3-19 | 69 | not low than 400 |
HP3018 | 3000*1800 | 150*250 | 3-19 | 83 | not low than 400 |
HP3618 | 3660*1800 | 150*250 | 3-19 | 99 | not low than 500 |
HP3021 | 3000*2100 | 150*250 | 4-19 | 96 | not low than 500 |
HP3621 | 3660*2100 | 150*250 | 4-19 | 116 | not low than 600 |
HP4221 | 4200*2100 | 150*250 | 4-19 | 135 | not low than 700 |
HP3624 | 3660*2440 | 150*250 | 4-19 | 132 | not low than 630 |
HP4224 | 4200*2440 | 150*250 | 4-19 | 154 | not low than 800 |
HP5024 | 5000*2440 | 150*250 | 4-19 | 184 | not low than1000 |
HP6024 | 6000*2440 | 150*250 | 5-22 | 220 | not low than 1000 |
HP5028 | 5000*2800 | 200*300 | 5-22 | 214 | not low than 1000 |
HP6028 | 6000*2800 | 200*300 | 5-22 | 257 | not low than 1250 |
4. Detail pictures of main part
Tempering furnace includes loading section, heating section, tempering section, unloading section. Also blowing system and controlling system.
5. Technical features
1). Adopting Jet Convection heating technology and have a flat quenching section and a bending quenching section
2) Each bending system has one individual fine adjusting device, slightly adjusting the local curve necessarily for the best possible quality products.
3). Adopting precise screw pairs in bending mechanism, which ensures smooth curve of bent glass. There will be no accumulated error in bending mechanism.
4) Different curves can be achieved by simply input the numbers via human-machine interface. With precise screw pairs in bending mechanism and servo control system, the end products are of high quality.
6.Packing and shipping
In containers.To be packed in standard export packing-suitable for long distance ocean.
7. Factory Picture
China Glass Tech Co., Ltd is specialized in the research, manufacturing and marketing of various kinds of glass and glass machinery, mainly including tempering furnace and tempered glass, insulated glass, laminated glass etc.
8.Exihibition
10.CE certification
