Double row fan Horizontal Roller Hearth Forced Convection glass laminated furnace

Specifications

1. Full automatic tempering furnace
2. Flat/bent tempering
3. Convection/radiation heating
4. Manufacture
5.CE, ISO standard

Double row fan Horizontal Roller Hearth Forced Convection glass laminated furnace





1. Brief Introduction

Tempering machineis used for producing large-size flat,tempered glass for architecture, and multi-curvature tempered glass for automobile, shower cabins and kitchen, etc. The type of sheet glass can be various such as float glass, coated glass, tinted glass,soft low-E glass etc.



2. Picture of glass laminated furnace



3. Technical parameter

Type	Max. size(mm)	Min. size(mm)	Thickness(mm)	Capacity(m2/h)	Power supply capacity(KVA)
HP1506	1500*600	90*90	3-8	14	not low than100
HP1508	1500*800	100*100	3-12	18	not low than150
HP2010	2000*1000	100*100	3-12	30	not low than 200
HP2012	2000*1200	120*120	3-12	37	not low than 250
HP2512	2500*1200	120*120	3-12	46	not low than 250
HP2515	2500*1500	150*250	3-19	57	not low than 315
HP3015	3000*1500	150*250	3-19	69	not low than 400
HP2518	2500*1800	150*250	3-19	69	not low than 400
HP3018	3000*1800	150*250	3-19	83	not low than 400
HP3618	3660*1800	150*250	3-19	99	not low than 500
HP3021	3000*2100	150*250	4-19	96	not low than 500
HP3621	3660*2100	150*250	4-19	116	not low than 600
HP4221	4200*2100	150*250	4-19	135	not low than 700
HP3624	3660*2440	150*250	4-19	132	not low than 630
HP4224	4200*2440	150*250	4-19	154	not low than 800
HP5024	5000*2440	150*250	4-19	184	not low than1000
HP6024	6000*2440	150*250	5-22	220	not low than 1000
HP5028	5000*2800	200*300	5-22	214	not low than 1000
HP6028	6000*2800	200*300	5-22	257	not low than 1250



4. Tempered glass application area

Building doors, windows, architectural glass, tempered glass, bending glass, bullet-proof glass.



5. Technical features

1). Adopting Jet Convection heating technology and have a flat quenching section and a bending quenching section

2) Each bending system has one individual fine adjusting device, slightly adjusting the local curve necessarily for the best possible quality products.
3). Adopting precise screw pairs in bending mechanism, which ensures smooth curve of bent glass. There will be no accumulated error in bending mechanism.
4) Different curves can be achieved by simply input the numbers via human-machine interface. With precise screw pairs in bending mechanism and servo control system, the end products are of high quality.





6.Packing and shipping

In containers.To be packed in standard export packing-suitable for long distance ocean.



7. Factory Picture

China Glass Tech Co., Ltd is specialized in the research, manufacturing and marketing of various kinds of glass and glass machinery, mainly including tempering furnace and tempered glass, insulated glass, laminated glass etc.
