Specifications
Full automatic Triaxial Triaxial machine1.Controlled by singlechip
2.Main frame is driven by servo motor
Full automatic Triaxial Triaxial machine
Feature:Controlled by singlechip, data setting of confining pressure and backpressure is by keyboard input., elavation of main frame is controlled. Main frame is driven by servo motor, and shearing rate is variable
Parameters:
1. Axial force: 0-10KN, measurement accuracy: ±1%
2. Shear rate: 0.001-2.4mm/min
3. Specimen size: Φ39.1×80mm
4. Confining pressure: 0-1Mpa
5. Backpressure: 0-1Mpa
6. Aperture pressure: 0-1Mpa
7. Volume change: 0-50ml
Features: computer control, curves and test reports can be printed
Accessories:
