WZB-SPM02 ZigBee Wireless Intrusion Detector
WZB-SPM02 is a Multi-Tech Motion Detector that detects movement (or human presence) in a given space (12m radius) using Passive Infrared (PIR), Active Infrared (AIR) and Micro-wave (MW) sensors. This dual-tech detection serves to enhance the devices reliability as the alarm is only triggered when both MW and PIR sensors are triggered. The infrared component also give the device an anti-masking function, increasing security and reliability. This device is fitted with Automatic Failure Detection (Anti-cloak) technology so if either the PIR or the MW sensors are faulty, malfunctioning or displaying abnormal behavior the device will automatically send a warning signal to the control panel. With both HA and Modbus capabilities this device is the perfect tool to integrate into any security system.
- PIR, Microwave and AIR Technology
- Dual-Element PIR sensor
- Function failure detection
- Temperature compensation
- Watchdog function
- Adjustable detection range
| Detection method | Passive Infrared and Microwave |
PIR Sensor | Dual-element |
| Microwave Sensor | X-Band Mono-static DRO |
| Microwave Frequency | 10.525 GHz |
| Anti-masking | AIR-SENSOR |
| Mounting Height | 2 meter |
| Power Input | 10~16V (12 VDC normal) |
| Detection Distance | 12 meter |
| Alarm Output (RELAY 2) | N.C , N.O , 30 VDC , 2A max |
| Failure Detection Output(RELAY 1) | N.C , N.O , 30 VDC , 2A max |
| LED Alarm Indicator | LED display for 3 sec |
| Warm up period | 40 seconds |
| Temperature Compensation | Automatic temperature compensation |
| Microwave power saving ability | Duty Cycle 5% |
| Auto Reset | Watch Dog Function |
| Operating Temperature | -10°C ~ 50°C |
| Material | ABS/ PC Alloy (Fire Resistant) |
| Dimensions | 132(L) x 65(W) x 54(H) mm |
1 Year Warranty. Original Made in Taiwan
R&R GROUP INTERNATIONAL
Taipei Taiwan, Hong Kong, Dubai UAE
