Durable water conductivity sensor cable, water leak sensing rope with CE&ROSH certificate
The length of the A-LC1B can be custom-made to any length within 400m.
Color and internal structure are also customizable ( Customize MOQ 500m)
| Product Features | |
| Cable diameter | 0.24 in(6.0mm)nominal |
| Sensing wires | 2*30 AWG with jacket of conductive fluoropolymer |
| Carrier | fluoropolymer |
| Cable weight(50 ft/15m length) | 2.3 lb (1kg) |
| Cable color | High-visibility yellow |
| Technical Information | |
| Breaking strength | Cable only:160 Ib(72KG) .Including connectors:70 Ib(32kg) |
| Cut-through force | >50Ib with 0.005(>22kg with with 0.13mm) in blade; cross head speed 0.2in/min |
| Abrasion resistance | >65 cycles per UL719 |
| Maximum continuous operating temperature | 70degree |
| Performance Data | |
| Leak size to alarm(tap water) | 2 in(50mm)maximum at any point along sensing cable ,up to 5000 ft maximum system length |
| Drying time | Cable dries and resets within 15 seconds removal rom standing water |
| Standard cleaning method | Wash with clean clean damp cloth |
Data Center
Water damage is the most unknown environmental threat for a data center. Once the leakage occurs under the raise floor, it can flood electric wires, cause heavy financial losses especially for the banking and telecommunication systems. Early detection will avoid catastrophic damages.
Wafer/Chip/Semiconductor Plants
The expensive equipment in these plants can be damaged once in contact with the liquid. More seriously, it will cause the production suspension.
Technical Room-MER/UPS Room
These rooms are critical to assure the good functioning of the whole building. In case of the leakage water in contact with UPS would paralysis the backup system, causing the most serious data damage loss. This is the crucial environment in which water leakage is unacceptable.
Museum & Library
Precious artistic work, highly protected cultural relic, rare specimen demonstrated in the museum and books deposited in libraries are concerned by 100% safety. Protection of water leakage is one of these priorities.
AnYing @ water leak detection cable detect the presence of water at any point along their length. Installed
with a AnYing locating module(A-LCIA),the cable senses water intrusion,triggers an alarm,and pinpoints the location.
Distributed sensing
A-LC1B water leak detection cable provide distributed leak detection and location over a wide range of areas.
The cable is available in a variety of lengths to provide as much coverage as needed.
Design flexibility
A-LC1B water leak detection cable is supplied with factory-installed plastic connectors that plug together.
water leak detection cable is designed of a range of applications,including data center subfloors,
telecommunication rooms
HVAC equipment locations,pipes,electrical vaults,storage areas,tanks,and roofs.
water leak detection cable is small,lightweitht,and flexible,allowing easy installation.The smooth design allows for quick drying.
Advanced technology
The conductive-polymer technology and fluoropolymer construction make A-LC1B water leak detection cable
mechanically strong and resistant to corrosion and abrasion.
water leak detection cable is constructed of two sensing wires,an alarm signal wire,and a continuity wire embedded in a fluoropolymer carrer rod.
The alarm module constantly monitors the sensing cable for continuity.
The rugged cable construction exposes no metal,and enables the cable to be reused even in corrosive environments.
