Home > Products > New Products > Intermediate Copper Wire Drawing Machine & Annealer
Intermediate Copper Wire Drawing Machine & Annealer
- 1 Set / Sets per Month
- Tianjin
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Inlet Diameter: | 6.5mm, 1.5-10mm | Outlet Diameter: | 1.7mm, 0.8-5.5mm | ||
Place of Origin: | Hebei, China | Model Number: | HY-WDM | Voltage: | 380v |
Power(W): | 37000 | Dimension(L*W*H): | 13000*1200*1500 | Weight: | 25TON |
Certification: | CE/ SGS/ISO | Warranty: | 1-2 years | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1no pollution2.drawing wire steady and uniform
3.nice shape and easy operation
4. 12 years experience
Wire Draw Machine/ Perforated metal mesh machine/ Mesh Bag Machine
Features:
- High speed and stable running
- Easy operation, AC frequency control
- Air cooling + Water cooling
- Vacuum system-Clean the dust, protect environment
- Capstan: Unique overlay welding technology, can use over 2000 hours
- Remote control: Find and solve electrical problems
Application:
It is applied for the production of prestressing strand, steel cord, bead wire, steel wire, spring steel wire, stainless steel wire, gas welding wire, arc welding wire,etc.
Specification:
Items | Unit | LZ9-12/1200 | LZ10/800 | LZ9/700 | LZ10/560 | LZ10/400 |
Reel diameter | mm | 900 | 800 | 700 | 560 | 400 |
Draw passage | time | 9-12 | 10 | 9 | 10 | 10 |
Incoming dia | mm | Φ14-8 | Φ10-8 | Φ8-6.5 | Φ6.5-5.5 | Φ14-8 |
Outgoing dia | mm | Φ5-3 | Φ4-3 | Φ3-2.5 | Φ2-1.8 | Φ1-0.8 |
Wire darwing line | m/min | 300 | 360 | 480 | 720 | 840 |
Incoming strength | Mpa | ≤1300 | ≤1300 | ≤1300 | ≤1300 | ≤1300 |
Total compressibility | % | 87.24-85.94 | 84-85.94 | 85.94-85.21 | 90.53-89.29 | 87.24-84 |
Average compressibility | % | 20.48-19.58 | 18.42-19.58 | 19.58-19.13 | 21.00-20.02 | 18.61-16.74 |
Single motor power | Kw | 110-90 | 90-55 | 75-55 | 37-22 | 15-7.5 |
Note: We can design the machine according to customers' requirements.
1. We will offer our best price asap when receive your inquiry about Anti Cut 358 security fence .
2. We can offer the sample free to you when you need to confirm it.
3. We can offer your products certifications for you, such as ISO9001,CE, material report.
4. We have many years experience, we can supply the best quality for you after receive your deposit.
5. In production time, we will strict control and test quality,then feedback to you.
Contact Us
- Beijing Hongye Metal Products Co., Ltd.
- Contact nameKate Hu
- Phone86-10-57273220,15201356809
- AddressRoom 515, 5/F, Building 26, Anningzhuang Road
