High-speed Bull Block Wire Drawing Machine

High-speed Bull Block Wire Drawing Machine photo-1
High-speed Bull Block Wire Drawing Machine photo-2
High-speed Bull Block Wire Drawing Machine photo-3
High-speed Bull Block Wire Drawing Machine photo-4
High-speed Bull Block Wire Drawing Machine photo-5
High-speed Bull Block Wire Drawing Machine photo-6
US$ 10,000 - 30,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New, New
Inlet Diameter:
6.5mm, 1.5-10mm
Outlet Diameter:
1.7mm, 0.8-5.5mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Inlet Diameter 6.5mm, 1.5-10mm
Outlet Diameter 1.7mm, 0.8-5.5mm
Place of Origin Hebei, China
Model Number HY-WDM
Voltage 380v
Power(W) 37000
Dimension(L*W*H) 13000*1200*1500
Weight 25TON
Certification CE/ SGS/ISO
Warranty 1-2 years
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1no pollution
2.drawing wire steady and uniform
3.nice shape and easy operation
4. 12 years experience



Product Description

 Wire Draw Machine/ Perforated metal mesh machine/ Mesh Bag Machine





High-speed Bull Block Wire Drawing Machine







High-speed Bull Block Wire Drawing Machine

 Features:

  1. High speed and stable running
  2. Easy operation, AC frequency control
  3. Air cooling + Water cooling
  4. Vacuum system-Clean the dust, protect environment
  5. Capstan: Unique overlay welding technology, can use over 2000 hours
  6. Remote control: Find and solve electrical problems

Application:



    It is applied for the production of prestressing strand, steel cord, bead wire, steel wire, spring steel wire, stainless steel wire, gas welding wire, arc welding wire,etc.







Specification:



ItemsUnitLZ9-12/1200LZ10/800LZ9/700LZ10/560LZ10/400
Reel diametermm900800700560400
Draw passagetime9-121091010
Incoming diammΦ14-8Φ10-8Φ8-6.5Φ6.5-5.5Φ14-8
Outgoing diammΦ5-3Φ4-3Φ3-2.5Φ2-1.8Φ1-0.8
Wire darwing linem/min300360480720840
Incoming strengthMpa≤1300≤1300≤1300≤1300≤1300
Total compressibility%87.24-85.9484-85.9485.94-85.2190.53-89.2987.24-84
Average compressibility%20.48-19.5818.42-19.5819.58-19.1321.00-20.0218.61-16.74
Single motor powerKw110-9090-5575-5537-2215-7.5





Note: We can design the machine according to customers' requirements.























Packaging & Shipping







Our Services

1. We will offer our best price asap when receive your inquiry about Anti Cut 358 security fence   .



2. We can offer the sample  free to you when you need to confirm it.



3. We can offer your products certifications for you, such as ISO9001,CE, material report.



4. We have many years experience, we can supply the best quality for you after receive your deposit.



5. In production time, we will strict control and test quality,then feedback to you.
