Help CenterSBG(2000)BIG CALBER CENIET HOLLOW WALL SPIRAL PIPE EXIRUSION LINE
Related Products
-
Plastic Rope Drawing MachineUS$ 35,000 - 42,000MOQ: 1 Set -
High Output Ultra-high Molecule Weight Polythelene Pipe Extrusion LineUS$ 100,000 - 500,000MOQ: 1 Set
-
DGD Maze Drizp Irrigation Tape Extrusion LineUS$ 5,000 - 20,000MOQ: 1 Set
-
125mm UHMWPE Pipe Extrution LineUS$ 20,000 - 39,000MOQ: 1 Set
-
UHMWPE Pipe ExtruderUS$ 20,000 - 39,000MOQ: 1 Set
According to national industry policy of“reply upon plastics instead of wood,reply upon plastics instead of steel,economize on energy and protect resources”, it is turned into the inexorable trend to speed up the popularization and application of chemical and environmental building materials and limit touse or eliminate the backward products, such as iron casting drain pipe zinc-plating pipe and even cement drain pipe. The large shortage of big caliber water supply and drainage pipe used for industry and agriculture drainage, sewage drainage, exhaust, coal mine ventilation, market drain, agriculture irriga-tion etc. and also the pipe of special use, at the same time the steel pipe and cement pipe have manydisadvantages such as they are difficult for construction and their prices are expensive, easy corrosion and short service life. Therefore,it has vast market development space to develop timely double wall bigcaliber spiral pipe for HDPE production.
BASIC COMPONENIS AND MAIN TECHNICAL DATA
Specification |
300- 800 |
800- 1600 |
1000- 2000 |
Single screw extruder |
SJ-90/30 |
SJ-100/30 |
SJ-120/30 |
Power of main motor |
75KW |
160KW |
185KW |
Extruder for extruding gel |
SJ-65/28 |
SJ-65/30 |
SJ-65/30 |
Power of main motor |
37KW |
45KW |
45KW |
Vacuum calibrating tank |
Tank length 6m |
Tank length 6m |
Tank length 6m |
Cooling tank |
Tank length 6m |
Tank length 6m |
Tank length 6m |
Haul-off unit |
0.5-6mm/min haul-off speed 0.5-6m/min |
0.5-6mm/min haul-off speed 0.5-6m/min |
0.5-6mm/min haul-off speed 0.5-6m/min |
Twining shaping unit |
|
|
|
Specification |
300- 800 |
800- 1600 |
1000- 2000 |
All data are subject to change notice.
