3 layer blown type HDPE geomembrane production line
- 100 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Black uv blocking water tank hdpe geomembrane making machine
-
1.5mm hdpe pond liner geomembrane extruder machine
-
3 layer 9m uv block hdpe geomembrane liner extrusion line
-
1.5mm hdpe liner geomembrane plastic sheet making machine
-
2mm hdpe dam lake liner geomembrane extrusion line
-
1.5mm hdpe landfill lining geomembrane film blowing machine
Product Details
| Condition | New | Application | Film | |
| Plastic Processed | Other, HDPE ,LDPE,LLDPE,EVA,mPE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Shandong, China | |
| Brand Name | Runhua | Model Number | TM3500 | |
| Voltage | 380V/50HZ(can adjust) | Power(W) | 550000w | |
| Dimension(L*W*H) | 18x12x21 (m) | Weight | 10000kg | |
| Certification | CERTIFICATE: CE, ISO9001, FTA, CO, SGS, CIQ | Warranty | 12 months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
3 layer blown type HDPE geomembrane production line
| |
Dear friends, thanks for visit our website, welcome.
Geomembrane film blowing machine are our company main product, we have 6 years export experience about this machine, we maintain the machine’s quality, that why our machine can sell very good in China, a lot geomembrane producer nearby us choose us without any hesitation. We can promise 1 year warranty for whole machine.
Our advantages | |
Technology | Details |
1. IBC internal bubble cooling system. | 1. Die head surface can reach mirror standard. |
2. Ultrasonic measurement and control technology. | 2. Guide roller with hard oxygen treatment. |
3. Synchronous traction technology. | 3. Extruder is designed by ourself, with good plasticizing capacity. |
We maintain every details. Our motto: Quality is first, customer is uppermost. | |
If you want to know more, please feel free to contact us, thank you.
Machine Type | 3FM2800 | 3FM3500 | 3FM5000-I | 3FM5000-II | 3FM5500-I | 3FM5500-II | |
Layer of laminating | 3 layers | ||||||
Raw material | LDPE,LLDPE,EVA,mLLDPE,HDPE | ||||||
Max. Output (kg/g) | 600 | 1000 | 1500 | 1800 | 2000 | 2300 | |
Extruder | 90/30x2 120/25x1 | 120/25x2 150/30x1 | 150/30x3 | 150/30x2 180/30x1 | 180/30x3 | 180/30x3 | |
Driving power (kw) | 90x2+110 | 110x2+200 | 250x3 | 250x3+280 | 280x3 | 315x3 | |
Diameter of die (mm) | 1400 | 1600 | 1800 | 2000 | 2200 | 2400 | |
Haul-off height (mm) | 19000 | 21000 | 24000 | 24000 | 27000 | 32000 | |
Traction speed (m/min) | 3~30 | ||||||
Layflat mode | Side gusset | ||||||
Geomembrane width (mm) | 5500 | 6300 | 7000 | 8000 | 9500 | 9500 | |
Geomembrane thickness (mm) | 0.3-2.4mm | ||||||
Total power (kw) | 750 | 950 | 1400 | 1550 | 1650 | 1900 | |
Overall dimension (m) | 16x9x20 | 18x12x21 | 19x11x25 | 20x13x25 | 20x15x27 | 22x22x33 | |
| |
| |
| |
Not all the usage can be listed.
Laiwu Runhua plastic Machinery Co., Ltd is a high technology enterprise which collects departments of Research& Development, Production, Sales and Service. We are specialized in plastic extruder, drawing machine, film blowing machine. Our engineers and experts have more than 20 years experiences.
Main products: Agriculture film machine, Geomembrane film machine, Packing film machine, Plastic wire drawing machine.
Our machine can prodcuce various plastic wires, plastic films. The max. width can reach 30 meters. Our machine could adopts 1-7 extruders ,can produce monolayer film and multi-layer film,can meet various needs.
Our motto: Quality comes first, Customer is the uppermost
Address: 123#, Longtan East Street, High-tech Zone, Laiwu city, Shandong Province
