20m Width Three Layers Film Extruder Machineries

Name: 20m Width Three Layers Film Extruder Machineries
Brand: RUNHUA
SKU: 141792894
Availability: InStock

US$ 10,000 - 12,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Film

Plastic Processed:

Other, LDPE. LLDPE and LDPE

Laiwu Runhua Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Film

Plastic Processed Other, LDPE. LLDPE and LDPE

Blow Moulding Type Extrusion Blow Moulding

Automatic No

Place of Origin Shandong, China

Brand Name RUNHUA

Model Number 3FM5500

Voltage 380v -3 phase

Certification ISO9001

Specifications

1.Blowing LDPE the mixture of LLDPE and LDPE
2.Thickness of film: 0.08-0.12
3.Film Width:2000mm

Main technical parameters

Type	3FM2800-	3FM3500-	3FM5000-	3FM5000-	3FM5500-	3FM5500-
Max. width(mm)	10000	12000	14000	16000	18000	20000
Film thickness(mm)	0.08~0.12
Layer of laminating	3
Raw material	LDPE,LLDPE,EVA,mLLDPE,HDPE
Max. output(kg/g)	600	1000	1500	1800	2000	2300
Extruder	90/30x2 120/25x1	120/25x2 150/30x1	150/30x3	150/30x2 180/30x1	180/30x3	180/30x3
Driving power(kw)	90x3+110	110x2+200	250x3	250x3+280	280x3	315x3
Diameter of die lip(mm)	1400	1600	1800	2000	2200	2400
Diameter of air ring(mm)	3600	3600
Haul-off height(mm)	19000	21000	24000	24000	27000	32000
Haul-off and wind-up speed(m/min)	3~30
Layflat mode	Side gusset
Wind-up method	Two-station center wind-up unit
	5500	6300	7000	8000
	0.3-2	0.3-2	0.3-2	0.3-2
Total power(kw)	750	950	1400	1550	1650	1900
Overall dimention(m)	16x9x20	18x12x21	19x11x25	20x13x25	20x15x27	22x22x33
