Help CenterPlastics Twin Screw Extruder/plastic Extruder/extruder Machine
Related Products
-
Plastics Twin Screw Extruder/plastic Extrusion Machine/production LineUS$ 10,000 - 50,000MOQ: 1 Set -
SSG(63)PVC One Mould Twin Pipe Extrusion LineUS$ 50,000 - 200,000MOQ: 1 Set
-
High Speed Plastic Pipe Extrusion MachineUS$ 100,000 - 500,000MOQ: 1 Set
-
High Speed Plastic Pipe Extrusion MachineUS$ 100,000 - 500,000MOQ: 1 Set
-
Two Screw Plastic Pipe Extruder Used for PP ,PE.PVC.PSUS$ 10,000 - 50,000MOQ: 1 Set
Since the designing and development of many years, the plastic twin screw extruders of the brand “RUN HUA” have formed the extruder series of. many kinds and diversified specifications. The
diameter scopes of the conical twin screws are from 51mm to 92mm, and the parallel twin screw are 65mm-145mm. They can be used to process the products, such as PVC pipe,plate,cable,
granule and so on. The extruder series own a lot of advantages: high efficiency, saving energy ,and long life etc.
model |
Screws Diameter(mm) |
Working Length mm |
Ratio(L/D) |
Screw Type |
Screw Speed(r/min) |
Max Output(kg/h) |
Driving Power(kw) |
Heating Power(kw) |
Center Height(mm) |
Dimension (LxWxH)mm |
Remarks |
SJSZ-51 |
51/105 |
1065 |
|
Conical |
3-34 |
110 |
18.5 |
12 |
1000 |
3620x1050x2157 |
|
SJSZ-55 |
55/110 |
1200 |
|
Conical |
3-34 |
130 |
22 |
18 |
1000 |
3500x1000x3000 |
|
SJSZ-65 |
65/132 |
1440 |
|
Conical |
1-34.7 |
235 |
37 |
26.4 |
1000 |
3550x1500x1550 |
|
SJSZ-80 |
80/156 |
1800 |
|
Conical |
1-34.7 |
360 |
55 |
36 |
1000 |
4750x1550x2460 |
|
SJSZ-92 |
92/188 |
2500 |
|
Conical |
1-34.7 |
750 |
90 |
68 |
1400 |
6000X1600x2500 |
|
SJS-65 |
65/24 |
|
24 |
Parallel |
5-50 |
120 |
22 |
20.9 |
1000 |
4390x1260x2600 |
|
SJSP-80 |
80 |
|
21 |
Parallel |
4.1-41 |
250 |
45 |
37.6 |
1000 |
4600x900x2200 |
|
SJSP-90 |
90 |
|
22 |
Parallel |
4.1-41 |
300 |
55 |
37.6 |
1000 |
3800x1250x2300 |
|
SJSP-120 |
120 |
|
20 |
Parallel |
40 |
550 |
90 |
60 |
1100 |
5601x2260x3000 |
|
Note: All the machines can not be listed because of various types.
All data are subject to change without notices.
