Specifications
The extruders series own a lot of advantages: high efficiency, saving energy ,and long life etcSince the designing and development of many years, the plastic twin screw extruders of the brand “RUN HUA” have formed the extruder series of. many kinds and diversified specifications. The
diameter scopes of the conical twin screw are from 51mm to 92mm, and the parallel twin screw are 65mm-145mm. They can be used to process the products, such as PVC pipe,plate,cable,
granule and so on. The extruder series own a lot of advantages: high efficiency, saving energy ,and long life etc.
model |
Screws Diameter(mm) |
Working Length mm |
Ratio(L/D) |
Screw Type |
Screw Speed(r/min) |
Max Output(kg/h) |
Driving Power(kw) |
Heating Power(kw) |
Center Height(mm) |
Dimension (LxWxH)mm |
Remarks |
SJSZ-51 |
51/105 |
1065 |
|
Conical |
3-34 |
110 |
18.5 |
12 |
1000 |
3620x1050x2157 |
|
SJSZ-55 |
55/110 |
1200 |
|
Conical |
3-34 |
130 |
22 |
18 |
1000 |
3500x1000x3000 |
|
SJSZ-65 |
65/132 |
1440 |
|
Conical |
1-34.7 |
235 |
37 |
26.4 |
1000 |
3550x1500x1550 |
|
SJSZ-80 |
80/156 |
1800 |
|
Conical |
1-34.7 |
360 |
55 |
36 |
1000 |
4750x1550x2460 |
|
SJSZ-92 |
92/188 |
2500 |
|
Conical |
1-34.7 |
750 |
90 |
68 |
1400 |
6000X1600x2500 |
|
SJS-65 |
65/24 |
|
24 |
Parallel |
5-50 |
120 |
22 |
20.9 |
1000 |
4390x1260x2600 |
|
SJSP-80 |
80 |
|
21 |
Parallel |
4.1-41 |
250 |
45 |
37.6 |
1000 |
4600x900x2200 |
|
SJSP-90 |
90 |
|
22 |
Parallel |
4.1-41 |
300 |
55 |
37.6 |
1000 |
3800x1250x2300 |
|
SJSP-120 |
120 |
|
20 |
Parallel |
40 |
550 |
90 |
60 |
1100 |
5601x2260x3000 |
|
Note: All the machines can not be listed because of various types.
All data are subject to change without notices.
