Single Crystal Copper Wire

compact stranded copper wire

Cable Construction

1.Fine bare copper strands

2.Stranding to BS 6360 Class 5 or IEC 60228 Class 5

3.Special PVC TI1 core insulation to BS 7655

Core Identification

Black, Blue, Green/Yellow, Red, Yellow, White, Violet, Brown, Grey, Orange, Pink

 1.Working voltage: 300/500v (H05V-K)/  450/750v (H07V-K)

2.Test voltage: 2000 -2500 volts

3.Minimum bending radius: 6xOverall diameter

4. Flexing temperature: -5º C to +70º C

5.Static temperature: -30º C to +80º C

6.Flame retardant: IEC 60332.1

7.Insulation resistance: 10 MΩxkm

Cable Parameter
