Aerial Power Cable

Name: Aerial Power Cable
Brand: Qunxing
SKU: 141763302
Availability: InStock

US$ 0.1 - 15 MOQ: 1 Kilometer

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

Qunxing

Model Number:

JKLYJ.JKLV,LKLY

Guangxi Qunxing Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name Qunxing

Model Number JKLYJ.JKLV,LKLY

Insulation Material XLPE

Type High Voltage

Application Overhead

Conductor Material Aluminum

Jacket PVC

Specifications

aerial power cable
1,Conductor: ALuminum,Copper
2,Insulation: XLPE
3,Armored:Option
4,Packing: wooden drum

aerial power cable

Conductor: aluminum

Insulation: XLPE

Standard:

Products are produced and provided according to GB / T 12527, GB / T 14049.

>Stable & process performance

>Strong ability to adapt to the environment

>Short circuit (the longest duration of not more than 5s)

>The maximum normal operating temperature of conductor 90°C

>Good flexibility, easy maintenance, installation, simple structure

>AC rated voltage 0.6/1kv,10KV for the fixed installation , transmission and distribution lines.

Code*Word	Phase conductor			Bare Neutral Message			Nominal lay Length	Weight Per		Allo wable Amp acitles
	Phase conductor			Bare Neutral Message			Nominal lay Length	1000 ft.(lbs.)		Allo wable Amp acitles
	Size	Stranding	Insul	Size	Stranding	Rated	inches	XLP	POLY	XLP	POLY
	(A WG)		Thick(Mils)	(AWG)		Strength
						(lbs.)
AAC Neutral-messenger
Clydessdale	4	1	45	4	7	881	20.58	198	198	100	80
Pinto	4	7	45	4	7	881	20.58	211	211	100	80
Mustang	2	7	45	2	7	1350	25.42	318	318	135	105
Criollo	1/0	9	60	1/0	7	1990	25.42	503	503	180	140
Percheron	2/0	11	60	2/0	7	2510	29.97	619	619	205	160
Hanovarian	3/0	17	60	3/0	19	3310	35.18	764	764	235	185
Oldenburg	4/0	18	60	4/0	19	4020	35.18	945	945	275	210
Lippizaner	336.4	19	80	336.4	19	6146	38.79	1519	1519	370	280
*Code words for XLP insulated products are formed by adding "/XLP" to the conventional code words above
+Conductor temperature of 90 for XLP,75 for Poly;ambient temperature of 40;emissivity 0.2;2ft./sec.Wind in sun.

NO.	Item	Optional
1	Product name	abc cable
2	Meterial	XLPE insulation
3	Color	Black or as your enquiry
4	Size	1.5~300mm2
5		or as your enquiry
6	MOQ	1000 meters
7	Packing	wooden drum
8	Price term	FOB shenzhen/Ningbo/Shanghai
9		Suggestion: ship by courier(FedEx, UPS, TNT)for small order(less than 500 pcs)will be cheaper
10	Shipping Methods	By sea, air or courier.
11		Courier: Fedex, DHL,UPS,TNT,EMS ets
12	Payment Terms	T/T,L/C,Western Union, Paypal.
13	Sample Lead-Time	5-7 days after receive your artwork or samples.
14	Production Lead-Time	25-30 days after your comfirmation to pre-production sample.
15	Remarks	Your own designs are welcome. Any logo, material,color,size and specification are available
16	Smaple Charge	Sample for your own disigns will be charged and courier charge should be in your acount
