China high techinical stone crusher , stone crusher machine for sale low price
China high techinical stone crusher , stone crusher machine for sale low price for sale low price series:
As one of the most popular stone crushing in the world, Jaw crusher is idealy suitable for primary and secondary crushing. The highest anti-pressure strength of crushed material is 320 Mpa. Our design and production which collect with Germany high technology are of high position both at home and abroad. As one of our main products, jaw crusher is designed by our engineers with large reduction ratio, even granularity, simple structure, reliable operation, easy maintenance, low operation cost. It is widely used in mining, metallurgy, construction, highway, railroad and chemistry industries
China high techinical stone crusher , stone crusher machine for sale low price works:
Yonran Series jaw crushers are overhead eccentric single toggle jaw crushers. The feed material is crushed between fixed and movable jaw dies. Movable jaw die is mounted to the pitman. Pitman motion (=kinematics) is defined by the eccentricity of the eccentric shaft and by the angle of the toggle plate. In Yonran Series jaw crushers the angle of the toggle plate is so steep that it amplifies the stroke from the top of the cavity to the bottom of the cavity. The result is a long and linear stroke in the bottom of the cavity which ensures great productivity and high reduction ratio. Cavity of the C Series jaw crushers works extremely efficiently from the very top to the bottom thanks to great feed opening dimensions, a good stroke up in the cavity, tight nip angle (angle between the fixed and movable jaw) and the long amplified linear stoke in the bottom of the cavity. The crusher size, weight, feed opening dimensions and capacity are all in good balance ensuring that with reasonable capital investment it is possible to process large feed and produce with good capacity. This ensures the best total economical feasibility of the primary crushing stage.
Use of China high techinical stone crusher , stone crusher machine for sale low price
SW jaw crushers are mainly used in medium and small size materials, such as coal, coal gangue, limestone, pyrite, etc. The largest block of the material need to be under the limit of it’s chosen model port (10-60 mm). Specific reference technical parameters as follows.
The compressive strength of the material to be broken should not exceed 1500kg / cm3. The output material size can be adjusted according to special requirements. Special requirements available (should be noted in advance).
Advantages: new design, simple structure, easy operation and maintenance.
Specifications for reference of China high techinical stone crusher , stone crusher machine for sale low price (mostly customized)
Model | SW-EP-150 | SW-EP-250 | SW-EP-400 | SW-EP-60 | SW-EP-100 | SW-EP-125 |
Feeding port(mm) | 150×250 | 250×400 | 400×600 | 60×100() | 100×125() | 125×150() |
Output adjustment range(mm) | 10-45 | 25-80 | 40-150 | 1-8 | 3-15 | 6-30 |
Mainshaft speed (r/min) | 310 | 285 | 285 | 360 | 480 | 385 |
Capacity | 1.0-4T/h | 5-16T/h | 10-30T/h | 0.15-0.5T/h | 0.2-0.1T/h | 0.5-1.2T/h |
Power (KW) | 5.5 | 15 | 30 | 1.5 | 3.0 | 3.0 |
Input dia (mm) | 125 | 210 | 350 | 50 | 80 | 100 |
Rated voltage (V) | 380 | 380 | 380 | 380 | 380 | 380 |
Weight (kg) | 860 | 1800 | 5200 | 135 | 340 | 320 |
1.Payment:30% T/T in advance, 30% T/T for production,40% T/T before shipment
2.Delivery Time: Within 30 days after receiving your advanced payment.
Shuiwang environmental protection equipment co.,ltd, establish in 2004, mainly focus on the design and manufacture of dredger, amphibious excavator, and mining equipment, aim to deliver a full range of equipment and services to meet various challenge of customers. Shuiwang's customer base includes dredging operators, mine owners, offshore contractors and government authorities, and also oversea dredger manufacturers.
Shuiwang provides a series of stanardrized products, different model will meet most of customers requirements. We also provide customized service to reach customers' special needs.
Along with Shuiwang's booming development, our featured products cannot handle more and more customres' requests. Besides bring new models, we also bring many new products to provide customers one-stop shopping service.
