0.5 ton-100 ton RO Water Treatment Equipment
The process water treatment system: | ||||||
| 1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter. | ||||||
| 2. Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect. | ||||||
| 3. Active Carbon filter-- Remove the color, free chloride, organic matter, harmful matter, ect. | ||||||
| 4. Softener-- exchange "ions" of calcium and magnesium with the most common and easiest method. | ||||||
| 5. Micron filter-- prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um, | ||||||
| 6. High pressure pump-- Provide the high pressure to RO membrane ro. | ||||||
| 7. RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.l |
Technical parameter
| Model | Production of water ; ( Ton/hour) | Motor power (kw) | Membrane | Entrance Diameter(mm) | Size(L*W*H)( mm) | Weight(Kg) |
| SW-0.5 | 0.5 | 1.1 | 4040 | φ32 | 1300*600*1400 | 100 |
| SW-1 | 1 | 1.5 | 4040 | φ32 | 1300*600*1400 | 100 |
| SW-2 | 2 | 3 | 4040 | φ38 | 1400*600*1400 | 200 |
| SW-3 | 3 | 4 | 8040 | φ48 | 1600*750*1750 | 200 |
| SW-4 | 4 | 5 | 8040 | φ48 | 2550*750*1750 | 250 |
| SW-5 | 5 | 7 | 8040 | φ60 | 2550*750*1750 | 300 |
| SW-10 | 10 | 11 | 8040 | φ60 | 3000*800*2000 | 600 |
| SW-15 | 15 | 16 | 8040 | φ72 | 3000*1250*2000 | 840 |
| SW-20 | 20 | 30 | 8040 | φ60 | 3000*1800*2000 | 1250 |
Features of RO Water Treatment System:
1) PLC control system.
2) 1 or 2-stage low-pressure reverses osmosis (RO) technology used
3) Low cost, no pollution, easy to operate
4) Convenient to install and dissemble
5) We can also modify or design new products, devices and functions
according to users' specific demands
Applications:
1) Water treatment for power plant, chemical, boiler
2) Water treatment for electronic semiconductor
3) Water treatment for medicine
4) Water treatment for food and drinking
5) Desalination of sea and brackish water
6) Waste water treatment for metallurgy, light industry, electroplating
1. Gritted rod
2. 1-100tons/h
3. Produces high quality water
4. Sealed chamber made of stainless steel
5. Automatically and manually wash RO membrane
6. The whole system has a long life, operation simple
7. No need to add any chemical, so no pollution, low produce cost
8. Adopts imported RO membrane, which can remove 97-98%
9. Widely used in beverage, brewing, medicine industry and so on
Trade Terms:
1.Payment:30% T/T in advance, 30% T/T for production,40% T/T before shipment
2.Delivery Time: Within 30 days after receiving your advanced payment.
