China Hot Sell Water Purification Equipment on Sale

Parameters

Product

Two stage Reverse Osmosis water treatment machine

Pure Water Production Capacity

6000 litre per hour(25°C)

Input water quality

TDS≤2000PPM(SDI≤5, 2≤PH≥11, NTU≤1)

Systematic Salt Rejection Rate

≥98%

Recovery Rate(pure water : inlet water)

50~75%

Recommended Working Temp.

5~35°C

Input Power(standard)

AC380V / 50Hz

Pre-treatment

Quartz Sand Filter(Flux: 6M3/H)

Φ900×1850mm(t=2.0mm) SUS304 stainless tank with 1200KG quartz sand

Or optional fiber glass tank, carbon steel lining rubber tank

Active Carbon Filter(Flux: 6M3/H)

Φ900×1850mm(t=2.0mm) SUS304 stainless tank with 350KG activated carbon

Or optional fiber glass tank, carbon steel lining rubber ta

Micron (PP Sediment) Filter

SUS304 stainless steel tank with 40inch PP filter×7PCS

Booster Pump

China Nanfang CHL8-30 pump×1PC

Multi-stage Pump for first stage RO

China Nanfang CDLS8-160 pump×1PC

Multi-stage Pump for second stage RO

China Nanfang CDL4-220 pump×1PC

Reverse Osmosis System

Membrane for first stage RO

U.S. HYDRANAUTIC ESPA-8040 membrane × 7PCS

Optional VONFRON membrane and DOW

Membrane for second stage RO

U.S. HYDRANAUTIC ESPA-8040 membrane × 5PCS

Optional VONFRON membrane and DOW

Accessories

Piping

SS304 connection

Touch-screen PLC control panel

America EMERSON PLC with colorful touch-screen operation

Others

Flow metre, TDS metre, pressure metre, electromagnetic valve, etc.

OPTIONAL

Chemical dosing System for PH adjustment, anti-scaling, etc.

U.S. Pulsafeeder Xo60 Automatic Dosing valve with 50L tank

UV sterilizer

IP67 waterproof grade UV-40W UV sterilizing(up to 5000hour lamp lifespan)

Or U.S. Hanovia lamp(up to 9000hours lamp lifespan)

Built-in chemical membrane washing device for RO system

For regular membrane cleanning so as to renew and improve the membrane performance
