Help Center2015 Gold Suction Dredger
Related Products
-
New Type Gold Extraction Dredger/machineUS$ 65,000 - 90,000MOQ: 1 Set -
China Efficient Sand Suction Gold Extraction MachineUS$ 65,000 - 90,000MOQ: 1 Set
-
Diamond and Gold Mining Equipment ManufacturerUS$ 65,000 - 75,000MOQ: 1 Set
-
Gold Diamond Dredging BoatUS$ 65,000 - 90,000MOQ: 1 Set
-
Cheap Bucket Chain Gold Dredger for SaleUS$ 25,000 - 40,000MOQ: 1 Set
120cbm/h Gold Separating Bucket Dredger
Main parameters
Pontoon length 22m
Single pontoon width 1.8m
Total width 5.2m
Pontoon height0.95m
Max. Dredging depth 8-15m
Output capacity 100-120m3/hr
Main engine one set of 75kw diesel engine generator set
5. Technical characters
5.1 Pontoon size
Single pontoon size:22*1.8*0.95m
Total pontoon size: 22*5.2*0.95m
5.2 Main engine
Diesel engine generator set
Set model: YNW -75GF
Set power: 75kw
Set speed: 1500rpm
Diesel engine model:R6105ZD
Diesel engine make: China Weifang
Diesel engine fuel consumption: 238g/kw.h
Diesel engine size: 2200×900×1450mm
5.3 Ladder and buckets
5.3.1 Ladder
Length 19.2m
Width1m
Height 0.65m
5.3.2 Buckets
Mouth length of bucket bottom 0.6m
Height0.35m
Capacity 0.05cum
Quantity 60
Model Y2-280-8
Capacity 22kw
Speed 760r/min
5.3.6 Reducer for buckets
Model ZQ750
Reduction ratio 48.57:1
5.4 Ladder winch 1 set
5.4.1 Reducer
ModelZQ350
Reduction ratio: 30.15:1
5.4.2 Electric motor
Capacity 11kw
Speed 960r/min
5.5 Ladder gantry
Height 3.8m
5.6 Drum screen
5.6.1 Drum screen
Model 900×1300
Diameter0.9m
Length 1.3m
5.6.2 Power and reducer
Power 5.5kw
Reducer 250
5.7 Gold chute
Length 4m
Width 1.1m
5.8 Waste chute
5.8.1 Stone chute
Width 0.6m
Length 5-7m
5.8.2 Sand chute
Length 3-5m
Width front: 1.1m back: 0.6m
5.10 Water pump
Model 65-108
Capacity 5.5kw
Rate of flow 65m³/h
Discharge distance 25m
5.11 Operating cabin
Size 2m*2.5m*2m
