US$ 1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Style:
Internal
Type:
Wired
Interface Type:
PCI
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Style Internal
Type Wired
Interface Type PCI
Transmission Rate 1024Kbps
Certification CE,EMC
Brand Name King Pigeon
Model Number DAM100
Place of Origin Guangdong, China

specification



GSM/GPRS Data Termination Unit (DTU) remote i o modules,
Data Acquisition Module,

digital thermometer module ,
Remote data transmission module,

 wireless data transceiver modules,

gsm modem module

2 Analog Input Module

Product Description

 Data Acquisition Module,2 Analog Input Module,DAM100



Name: Data Acquisition Module,2 Analog Input Module

Model:DAM100



The DAM100 is for monitoring 2 analog inputs(0~20mA,4~20mA,0~5V,0~10V, or AC and DC 0~5A, 0~500V). It supports Modbus RTU Protocol over RS485 serial port. Powered up by 10~30VDC.









 Data Acquisition Module,2 Analog Input Module,DAM100



Specifications:







Items

Specifications

Rated Power Input

10~30VDC(Peak Voltage must≤40V)

Power Consumption

Typically ≤3W

Communication Protocol

Modbus RTU

Modbus Address

1~247

Data Format

n,8,1; e,8,1; o,8,1 or n,8,2

Communication Interface

RS485

Baud Rate

1200, 2400, 4800, 9600, 19200, 38400Bps

Analog Input

Default: 4~20mA, optional: 0~20mA, 0~5V, 0~10V

Update Period

0.12~2.4S

Measurement Precision

±0.2%FS

Input Resistance

Analog channel: Voltage:>1KΩ, current ≤150Ω

Overload Capacity

1.2 times can sustained,3 times voltage can last 1 second.

Isolated Type

Input / power / RS485 Serial port / drivable output use the same GND, no isolated.

Withstand Tests

Input /Shell: 2000VAC/min.; 500VDC>100 MΩ

Installation Type

35mm DIN Rail

Operation Temperature

-20~70℃;

Storage Temperature

-40~85℃;

Relative Humidity

5~95%RH.;(at -40℃, non condensate)

Altitude

0~3000m

Temperature Drift

≤100ppm/℃

Dimension

118×72×59mm mm(HxWxD)

Net Weight

160g.





Mainly Features:



Wide range power supply with reverse polarity connection protection;



Modbus RTU Protocol;



ESD Protection circuit for RS485 serial port;



Using industrial-grade chips;



Built-in watchdog ensure it reliability;



Data Acquisition Module,2 Analog Input Module,DAM100
