Diesel Generator
- 50 Piece / Pieces per Month
- Shanghai / Ningbo
- Credit Card
Product Details
Place of Origin: | Shanghai, China | Model Number: | NVC138-60 | Output Type: | AC Three Phase |
Speed: | 1800 RPM | Rated Power: | 30 KV | Rated Voltage: | 230/400V |
Rated Current: | 60 HZ |
Product Description
Specifications
Diesel Generator1 High quality
2 sound proof
3 Good design
Diesel Generator
Model | Stanby Power | Prime Power | Engine | Alternator | Diemensions | Weight | ||||
KVA / KW | KVA/KW | Manufacturer | Model | Manufacturer | Model | L * H * W (mm) | (kg) | |||
NVC168-60 | 150 | 120 | 137.5 | 110 | Cummins | 6BTAA5.9-G2 | Stamford | UCI274D | 2210×830×1355 | 1160 |
Prime Power (PRP): Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(eqvISO8528): A 10% overload capability is available for a period of 1hour within 12-hour period of operation.
Standby Power (ESP): The Standby Power is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
I. Scope of supply | ||||||||||
1. Brand new diesel engine. | ||||||||||
2. Brand new AC atlernator, Ratings: 230/400v, 3Ph, 60Hz, 1800Rpm, 0.8PF, IP22, " H"classinsulation | ||||||||||
3. Standard Radiator mounted on skid. | ||||||||||
4. Manual control panel consisting of: Emergency Stop button, Voltmeter and selector switch, Ammeter and selector switch, Frequency meter, Oil pressure gauge, Water Temperature gauge. | ||||||||||
5. Circuit breaker. | ||||||||||
6. Hight effient shock absorb | ||||||||||
7. 24V lead acid battery and battery cables and battery rack | ||||||||||
8. Dry type air filter, fuel filter, oil filter | ||||||||||
9. Silencers with flexible connection pipe | ||||||||||
10. All silent type genset will be with a base fuel tank for at least 8 hours running, | ||||||||||
11. English operation/maintenance manuals/test report for engine, alternator and genset. | ||||||||||
12.Standard tools kit. |
