Diesel Generator
US$ 4,800 - 20,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Model Number:
NV15GF-60
Output Type:
AC Three Phase
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai / Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shanghai, China
Model Number
NV15GF-60
Output Type
AC Three Phase
Speed
1800 RPM
Rated Power
21 KV
Rated Voltage
230/400V
Rated Current
60 HZ
Specifications
Diesel Generator1 High quality
2 sound proof
3 Good design
Diesel Generator
| Model | Stanby Power | Prime Power | Engine | Alternator | Diemensions | Weight | ||||
| KVA / KW | KVA/KW | Manufacturer | Model | Manufacturer | Model | L * H * W (mm) | (kg) | |||
| NV15GF-60 | 21 | 16.5 | 19 | 15 | Laidong | KM485BD-4 | Marathon | 281CSL1504 | 1240×560×940 | 385 |
Prime Power (PRP): Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97(eqvISO8528): A 10% overload capability is available for a period of 1hour within 12-hour period of operation.
Standby Power (ESP): The Standby Power is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
| I. Scope of supply | ||||||||||
| 1. Brand new diesel engine. | ||||||||||
| 2. Brand new AC atlernator, Ratings: 230/400v, 3Ph, 60Hz, 1800Rpm, 0.8PF, IP22, " H"classinsulation | ||||||||||
| 3. Standard Radiator mounted on skid. | ||||||||||
| 4. Manual control panel consisting of: Emergency Stop button, Voltmeter and selector switch, Ammeter and selector switch, Frequency meter, Oil pressure gauge, Water Temperature gauge. | ||||||||||
| 5. Circuit breaker. | ||||||||||
| 6. Hight effient shock absorb | ||||||||||
| 7. 24V lead acid battery and battery cables and battery rack | ||||||||||
| 8. Dry type air filter, fuel filter, oil filter | ||||||||||
| 9. Silencers with flexible connection pipe | ||||||||||
| 10. All silent type genset will be with a base fuel tank for at least 8 hours running, | ||||||||||
| 11. English operation/maintenance manuals/test report for engine, alternator and genset. | ||||||||||
| 12.Standard tools kit. |
