Products Specifications:
DIMENSIONS |
| ||||||||||||
Tare weight | 11000kg | Payload | 60000 kg |
| |||||||||
Overall length | 10950mm | Overall width | 2500mm | Overall height | 3620mm | ||||||||
SPECIFICATION | |||||||||||||
Chassis | Heavy duty and extra durability designed I beam;opting for high tensile steel Q345,welded by automatic submerged-Aac processes. | ||||||||||||
Axle | Number | 3 | Brand | Fuwa | Capacity | 13T | |||||||
Suspension | Mechanical suspension |
| |||||||||||
Leaf spring | Leaf spring 7 pcs |
| |||||||||||
Floor | 8mm plate .side wall 6mm |
| |||||||||||
Tire | 12R22.5 12 pcs |
| |||||||||||
Wheel rim | 9.0 |
| |||||||||||
Kingpin | 2’’ bolt-in king pin |
| |||||||||||
Landing gear | two-speed,manual operating ,heavy duty landing gear 24t |
| |||||||||||
Cylinder | HYVA |
| |||||||||||
Vehicular applications | Sand and pebble and mineral transport |
| |||||||||||
Drawing | Including |
| |||||||||||
Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| |||||||||||
Paiting | Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint |
| |||||||||||
Accessories | One standard tool box | ||||||||||||
