Help CenterIndustrial Fruit Drying Chamber/meat Drying Box/food Drying Oven
Related Products
-
Bottle Filling Capping and Labeling MachineUS$ 6,000 - 9,999MOQ: 1 Set -
Liquid Injection Filling MachineUS$ 6,000 - 9,999MOQ: 1 Set
-
Honey Filling Packing Machine,automatic Filling Capping MachineUS$ 9,998 - 9,999MOQ: 1 Set
-
Auto Filling Production LineNegotiableMOQ: 1 Set
-
90 Degree Belt ConveyorUS$ 1,000 - 4,999MOQ: 1 Set
Specifications
1.fruit and vegetable dryer2. stainless steel
3. multifunction, dry meat, vegetable, chemical, medicine
Quick Details
| Condition: | Place of Origin: | Brand Name: | |||
| Model Number: | Type: | Voltage: | |||
| Power(W): | Weight: | Dimension(L*W*H): | |||
| Certification: | Warranty: | Dimension: |
Packaging & Delivery
| Packaging Detail: | plywood |
| Delivery Detail: | 15 days after payment |
Specifications
1.fruit and vegetable dryer
2. stainless steel
3. multifunction, dry meat, vegetable, chemical, medicine
This tray dryer was upgraded and regenerated for several times and has reached advanced level both at home and all over the world. After being filtered by the primary filter fixed at the air inlet, the clean air will be blown into thedrying chamber and flow towards the electrical heater. Then the heated air will be evenly distributed to each layer of trays. The hot air penetrates through the raw material via the holes punched at the tray bottom to evaporate the moisture from the raw material. Some of the moisture will be exhausted through the exhaust vent and new fresh air will be brought in to supplement the circulation air.
Technical explanation :
1. There are four kinds of heating resource for choice: steam, electricity, heat conducting oil, both steam and electricity.
2. The temperature (steam heating): 50-140°C, Max 150
3. The temperature (when using electricity and far-infrared): 50-300°C
4. The automatic control system or the computer control system is selectable.
5. Commonly used steam pressure 0.2-0.8 MPa (2-8kg/cm2).
6. Standard electric heating , easy flammable and explosive material is forbidden.
7. The special requirements should be indicated at the time of order.
8. The price for the non-standard oven should be consulted.
9. If the operation temperature is more than 140°C or less than 60°C, it should be indicated at the time of order.10. The oven and baking tray made by our factory are uniform in the dimensions, and can be exchanged with each other.
11. Baking tray dimensions: 460*640*45mm
12. Explosive-proof motor and control cabinet as option.
Advantages and features:
1. Energy saving:Most of the air is circulating inside the drying chamber which can considerably save the energy
2. Sanitary working condition: The inside surface is lined with stainless steel and full welded. The sealed working condition can make
sure sanitary working condition.
3. Uniform drying temperature:air distributor is fixed at each side of the drying chamber to make sure uniform air flow. So thetemperaturedifference between the top and bottom is less than 2 °C. So the raw material can evenly dried.
4. Easy temperature control: The drying temperature can be easily controlled by PLC control system.
5. Low noise working condition:Heat resisting and low noise circulation fan is combined.
Main technical parameter:
Model | Number of Trolley | Number of Plate | Motor | Area of the plates | Productivity | Dimension (m) |
LW-1 | 1 | 24 | 9kw | 5.76m² | 50kg/8h | 1.55*0.8*2.2 |
LW-2 | 2 | 48 | 12kw | 11.52m² | 100kg/8h | 2.1*1.1*2.3 |
LW-4 | 4 | 96 | 18kw | 23.04m² | 200kg/8h | 2.1*2*2.3 |
LW-6 | 6 | 144 | 22kw | 34.56m² | 300kg/8h | 2.6*2.1*2.3 |
LW-8 | 8 | 192 | 30kw | 46.08m² | 400kg/8h | 4*2*2.3 |
