width adjustable international food grade belt conveyor equipment
1.Conveyor body part:
1.1 Main body side chain plate:Plate thickness:δ2.0mm Material:SUS304.
When produced according to the actual size.
1.2 Roller:Material SUS304,diameter is based one the actual
load,cooperate with the plus or minus tolerance.
1.3 Riding wheel:Material Nylon processing molding,diameter is based one the actual load,cooperate with the plus or minus tolerance.
1.4 Bun foot:Nylon injection molding,Cooperate with stainless steel adjusting screwM16.
1.5 Guardrail part adopts big Caluminum trackCooperate with wear-resisting sheath;
1.6 Connecting plate:plate wicknessδ3.0mm Material:Stainless steel bending forming;
1.7 Accessories:Mounted Bearings,kinds of SUS304 screws,etc.
2.Conveying carrier part
2.1 Belt length<According to the effective length*widthness (mm)(When produced according to the actual size);
2.2 Belt flange:Apron edge,With baffle,height can be made by their actual size;
2.3 Material:PVC,PU;
2.4 Color:White,Blue,Green.
3.Power system
3.1 Gear motor:Worm gear and worm gear motor,
Protection classIP55,Power P=1.5KW/0.75KW;
3.2 Speed:V=0—25 Meter/MIN;
3.3 Speed choice: Denmark Danfoss inverter frequency control motor speed.
4.Control Segment
4.1 Electric cabinet material:1.5mm SUS304 Stainless steel plate bending welding forming.
4.2 Electronic components:disconnector,AC contactor, button switch,etc. Brand: Schneider,France.
the pictures of turning conveyor
2.once we get your order we will arrange the delivery as soon as possible
3.after order ,we will provide you with our best after-service.
Shanghai LEADWORLD MACHINERY TECHNOLOGY CO.,Ltd. is specialized in developing researching and manufacturing various whole set of packing production systems ,also it owns marketing ,import&export ability .Based on enormous technology strength ,we regard market demand as our guide ,production development as our responsibility ,we can design the best economical reasonable solution program.
our company have passed ISO9001:2008 international quality management system ,established integrity Quality guarantee system ,to insure the quality and performance of our products.
our company mainly produce filling machine ,packing machine ,capping machine ,bottle washing machine ,labelling machine and other food production line.
