Specifications
Name:Mini conveyor1.Simple structure
2.Easy to maintain
3.Large throughout
4.Standard parts
Name:Mini conveyor
Advantages:
1.Simple structure
2.Easy to maintain
3.Large throughout
4.Standard parts
Introduction:
The conveyors consist of standard parts, which are advanced and simple in structure, easy to maintain.They are widely used in mining, metallurgical and coal industry to transfer sandy or lump materials, or packaged materials. According to different transferring equipment, the transfer system can be one independently or multi-conveyors or combined with other transfer equipments.
Main technical parameters:
|
Belt Width (mm) |
Belt Length(m) Power(kw) |
Belt Speed (m/s) |
Capacity (t/h) |
||
B400 |
≤12/1.5 |
12-20/2.2 |
20-25/3 |
0.8-2 |
40-80 |
B500 |
≤12/3 |
12-20/4 |
20-30/5.5 |
0.8-2 |
78-191 |
B650 |
≤12/4 |
12-20/5.5 |
20-30/7.5 |
0.8-2 |
131-323 |
B800 |
≤10/4 |
10-15/5.5 |
15-25/7.5 |
1.0-2 |
278-546 |
B1000 |
≤10/5.5 |
10-20/7.5 |
20-25/11 |
1.0-2 |
435-853 |
B1200 |
≤10/7.5 |
10-20/11 |
20-25/15 |
1.0-2 |
655-1284 |
