Microporous Insulation Board
- 50000 Square Meter / Square Meters per Month
- Qingdao
- T/T
- Shandong supplier fiber reinforced calcium silicate board
- Placa de silicato de calcio 1000 * 500 * 50 mm
- High density thermal insulation material, high-temperature refractory lining
- High density calcium silicate board, carbon fiber, glass fiber
- High density non stick calcium aluminosilicate board
- Cement plant, power plant, aluminum plant, steel plant, chemical plant, metallurgical industry, thermal insulation board
Product Details
Place of Origin: | Henan, China | Material: | Other, Nano insulation panel | Model Number: | M 5100 |
Product Description
Temperature grades available : 850C, 1000C , 1100C, 1200C
Standard Covering:Naked,PE Film,Aluminium Foil(2/6 sides),Fiber Paper, E-glass Fiber Cloth
Maximum size: 2450x650 x(10 to 50mm)
M5100 Board is rigid finishing from microporous technology , with opcified blend of filament reinforced fumed silica, which provides a superb thermal performance.
It is an ideal back-up insulation for various industry where the high temperature is needed, with a long time exposure of 1150 °C at highest.
M5100 Board ---Various coverings : Naked Panels, Aluminium Foil covering, E-class Fibre Cloth Covering, Fibre Paper covering.
M5100 Board—Four Grades available : 850 , 1000, 1100, 1200
Properties & Advantages
Extremely low thermal conductivity
High thermal stability
High compressive strength
No harmful respirable fibres
Free of organic binders
Environmentally friendly
Resistant to most chemicals
Non combustible
Easy to handle
Typical Applications
Back-up insulation in industrial furnaces
Fuel cells (SOFC)
Thermal Batteries
Aluminium industry ( launders,Smelter.etc. )
Glass & ceramics industry
Petrochemical industry (cracking furnace, reformer)
Black box & VDR (Voyage Data Recorder)
Data loggers
Working & Processing
M5100 can be shaped both manually and with stationary wood processing machinery. They can be cut, sawn, drilled and punched. The boards can be fixed in place with glue or by mechanical means such as anchors, pins and clips.
Technical Data
Description | M5100 | ||||
Classification Temperature | 0C | 850 | 1000 | 1100/1100S | 1200/1200S |
Long time Exposure | 850 | 950 | 1050/1000 | 1150/1100 | |
Nominal Density | [kg/m3] | 260-280 | 260-280 | 400-450 | 450-550 |
Typical Density | 280 | 280 | 450 | 500 | |
Compression Strength | [MPa] | 0.32 | 0.32 | 0.72 | 0.8 |
@10% deformation (ASTM C-165) | |||||
Thermal Conductivity | |||||
200 0C | W/m.K | 0.022 | 0.022 | 0.024 0.028 | 0.027 0.029 |
400 0C | W/m.K | 0.025 | 0.025 | 0.028 0.032 | 0.032 0.035 |
600 0C | W/m.K | 0.028 | 0.028 | 0.032 0.038 | 0.037 0.042 |
800 0C | W/m.K | 0.033 | 0.033 | 0.035 0.045 | 0.043 0.046 |
Specific Heat Capacity | |||||
200 0C | [KJ/Kg K] | 0.85 | 0.86 | 0.86 | 0.89 |
400 0C | [KJ/Kg K] | 0.95 | 0.96 | 0.97 | 0.99 |
600 0C | [KJ/Kg K] | 1.02 | 1.03 | 1.04 | 1.05 |
800 0C | [KJ/Kg K] | 1.07 | 1.08 | 1.08 | 1.08 |
Linear Shrinkage | |||||
12h full soak @ 850 0C | % | ≤2 | ≤0.5 | ≤0.1 ≤0.1 | ≤0.1 ≤0.1 |
24h full soak @ 950 0C | - - - | ≤2.5 | ≤0.5 ≤0.1 | ≤0.5 ≤0.5 | |
24h full soak @ 1050 0C | - - - | - - - | ≤2.5 - - - | ≤2.5 ≤2.5 | |
24h full soak @ 1150 0C | - - - | - - - | - - - - - - | ≤3.5 - - - |
