42 m3 3 Axles Oil Tank Trailer Truck with Shacman Tractor
Oil Tank Trailer Truck is also called Tanker Tractor semitrailer ,cargo semitrailer ,mobile transport truck,tanker truck semitrailer,etc, widely used in transporting and discharging gasline, diesel and other fuel product. We can supply tanker ranged from 4000L to 45000L,Tanker Semitrailer ranged from 30000L to 6000L. Experience of ten years of manufacturing pressure vessel ensure reliable quality. Use this type of semitrailer can improve transport efficiency 30-50%, reduce cost 30% -40%, reduce fuel consumption 20%- 30%.
Technical Parameter of 42 m3 3 Axles Oil Tank Trailer Truck with Shacman Tractor
Product Model | CLW Oil Tank Trailer Truck | Overall Dimension(L*W*H)(mm) | 11000×2500×3850 |
Tank Volume(m3) | 42 | Tank Dimension(mm) | Front-end(3900×2480×1800) rear-end(6800×2480×2040) |
Gross weight (kg) | 39800 | Approach/ departure angle (° ) | -/22 |
Payload(kg) | 28000 | Front/ rear suspension(mm) | -/1410 |
Curb weight(kg) | 11800 | Leaf Spring number: | -/8/8/8 |
Axle number | 3 | Front/Rear axle load(Kgs) | -/23800 (three-axis combined) |
Wheelbase(mm) | 5760+1310+1310 | Rear tread(mm) | 1840/1840/1840 |
Tire size | 11.00R20 12PR | Tire No: | 12 with a spare |
Warranty | 12 months, from the date of supply | ||
Remarks | 1.Protective material: carbon steel, storage medium: gasoline | ||
2.Use the tractor equipped with speed limit device better | |||
3.Tank material: 6mm carbon steel, 90mm saddle | |||
Technical Parameter of Shacman Delong 385HP 6*4 Tractor Unit
Main Technical Parameter | |||
Product Model | Shacman Tractor Unit | Overall Dimension(L*W*H)(mm) | 6635×2490×3640 |
Gross weight (kg) | 25000 | Total Mass of Quasi-trailer(Kg) | 45000 |
Wheelbase(mm) | 2925+1350 | Axle number | 3 |
Curb weight(kg) | 9000 | Max Speed (km/h) | 92 |
Cab capacity | 3 | Cab Type | F3000 Flat proof Cab, air conditioning |
Chassis Technical Parameter | |||
Gear Box | 12JS160T (Fuller 12 speeds) | Transmission type: | Manual |
Brake System | breathe brake system with ABS | Leaf Spring number: | 9,10/12 |
Traction Type: | 6*4 | Steering Type | LHD or RHD with power steering |
Tire size | 11.00-20,11.00R20 16PR,12.00-20 16PR,12.00R20 14PR | Number of Tire | 10 with a spare |
Engine specification | |||
Engine Model: | ISME385 30 | Engine Brand | American |
Emission stand | Euro 3 | Displacement(ml) | 10800 |
Fuel type: | Diesel | Power(kw) | 283/385HP |
Other equipment | 1. Equipped with ABS and driving recorder, Optional Equipped with speed limit device | ||
2. With 2' or 3-1/2' kingpin | |||
Warranty | 12 months, from the date of supply | ||
Product Picture of this Oil Tank Trailer Truck show as following:
1, Packaging: nude or waxing;
2. Shipping: in the container or Ro-Ro ship or bulk ship according to the customer’ order or requirement;
1. Factory direct supply: reliable quality and fast delivery;
2. Warranty; from the date of receiving, in normal use within 30000kh or within one year, we will repair for free, but the wearing parts and electrical parts are not included. After one year, we only charge cost when the question occurs;
3. Tracking service: lifelong
4. Chassis question: when the question occurs, please find the local nearest Service Station for repair or maintenance, or call us if the local have no Chassis Service Station;
5. Spare Parts: Superstructure spare parts is sent by ourselves, we only charge cost; Chassis spare parts is sent by the local Service station, if the local have no chassis service station, please call us freely.
6. OEM Ability: We can customize the truck according to your request, such as material, size, color, paint, logo, etc.
7. Warm tip: please operate, use, and maintain the truck according to our manuals and Instructions. When the question occurs, please call us freely.
Brief Introduction of Company:
ChengLi Special Automobile Co., Ltd ,which is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks. It has registered trademark"CHENLIWEI" and the products code is CLW. It has solid technology,flawless inspection,advanced equipments,reliant quality and flexible modes of operation. What's more, it has roundly passed the certificaton of ISO 9001-2008 and the 3C Certification(China Compulsory Certification) and other certifications that export needed.
Since ChengLi company was established in Sep. 2004, ChengLi Special Trucks have always taken the top place in Chinese market in recent ten years and have procured remarkable achievements interiorly and oversea.
We can design and produce many kinds of special trucks accurately as your request. Our company own independent export right, and has a mount of clients overseas, such as the U.N., Sudan, Nigeria, North America, West Africa, Congo, Vietnam Ghana, Kazakhstan etc. We strives for the survival by the quality and credit standing is the guarantee of our success.
ChengLi Special Automobile co.,Ltd is located in Suizhou City, the native place of YanDi ShenNong,the hometown of BianZhong and the City of Special Truck. Welcome the friends from all over the world to SuiZhou! You will be the most enthusiastic reception.
Our certificates;
Production Equipments:
1. Are you manufacturer or trading company?
We are direct manufacturer;
2. Min Order Quantity:
One unit or one sets;
3. Handling Time:
Within one day;
4. Payment Terms:
30% deposit, 70% balance before shipment by TT or Irrevocable LC at sight;
5. Specified delivery date from the Date of Order:
Depend on the detailed request and purchase order quantity.
6. Contact Information:
For any question or request, please contact with me freely according to the following information:
