FONTON FORLAND 4*2 Mini Refrigerator Van Truck
Refrigerator Van Truck is also called Refrigerator Box Truck ,Refrigerated van Truck refrigeration transport truck, insulation truck, refrigeration van truck, freezer truck, mechanical refregerated truck,etc. It is fully enclosed truck which is mainly used in transporting frozen or fresh goods,such as frozen foods,milk products, vegetable,fruit,vaccine, medicines,etc. It usually equips with refrigeration unit and polyurethane heat insulation case. It is refrigeration special transport trucks.
Product Note:
1. "CLW" refrigeration truck adop fully enclosed composite structure, inside and outside FRP, middle polyurethane foam heat insulation material, all-around is bonded together with high stength glue ,overall thickness is 10cm.(optional 20cm)
2. Appearance of smooth, flame retardant type insulation material , food-grade gelcoat, seamless whole panel
3. "CLW" seried refrigeration truck have features such as corrosion-resistant, good insulation properties, high strength ,light weight,good chemical stability, long life,etc.
4. Factory direct sale,professional, adop FONTON FORLAND 4*2 truck chassis with 61hp gasoline engine, economical, practical, Min temperature be dropped to -18°C
Main parameter of FONTON FORLAND 4*2 Mini Refrigerator Van Truck
Whole Truck main technical parameter | |||
Product Model | FONTON FORLAND Refrigerator Van Truck | Overall Dimension(L*W*H)(mm) | 4360×1600×2400 |
Load Weight(kg) | Approx 1500 | Compartment Dimension(mm) | 2580×1390×1470 |
Curb weight(kg) | 1256 | Approach/ departure angle (° ) | 24/28 |
Cab capacity | 2 | Max Speed (km/h) | 90 |
Chassis Technical Parameter | |||
Chassis Model: | BJ1020V3JV2-X | Chassis Manufacturer: | BEIQI FONTON Automobile Co., Ltd |
Brake System | Air brake | Transmission type: | Manual with 5 shift |
Front/ rear suspension(mm) | 895/1195 | Leaf Spring number: | -/5,-/6 |
Axle number | 2 | Front/Rear axle load(Kg) | 754/1130 |
Wheelbase(mm) | 2370 | Front/Rear tread(mm) | 1260/ 1260 |
Tire size | 175/70R14LT | Traction Type: | 4*2 |
Engine specification | |||
Engine Model: | LJ465Q-2AE | Engine Brand | Liuji Power |
Emission stand | Euro 4 | Displacement(ml) | 1051 |
Fuel type: | gasoline | Power(kw) | 45/61hp |
Warranty | 12 months, from the date of supply | ||
other Equipment or performances | 1. Don’t open at the top, optional open side door | ||
2. Equipped with DM-050S refrigeration unit(optional other brand) | |||
3. Minimum temperature can be dropped to -18 °C. | |||
4. Material: FRP inside and outside, 10cm thickness polyurethane foam middle. | |||
Warm tips:
A. Refrigeration unit Brand Optioanl : American CARRIER dalengwang, South Korea hanya, China Songhan, hanxue,etc.
B. Minimum temperature optional: -5 °C to -18 °C
C. The refrigeration units that we select have simple structure, convenient operation , reliable working, low energy consumption ,large refrigerating capacity, small noise , easy installation and maintenance and other advantages, it will sure you use safe!
Picture of Refrigerator Van Truck show as following:
More picture of Refrigerator Van Truck show as following:
