Howo 32m fire truck with aerial ladder, Sino fire sprinkler truck

Howo 32m fire truck with aerial ladder, Sino fire sprinkler truck

Ms Joyce :+008613545915671

1) Dimension: length x width x height

   11000×2500×3900 (mm)

2) min. turning radius less than 10m

3) Proximal angle more than 16 degree

4) Off angle more than 10 degree

5) Max. Climbing capacity more than 45%

6) Full loading mass 19000 kg

7) Max. speed more than 90Km/h

8) span of the outrigger: longitudinal distance 5300 mm

     Transverse distance 5500 mm

9) Ladder working height: 32 m(from ground to work cage )

10) Ladder elevating angle: - 12degree – 75 degree

11) Swing range: 360 degree infinite rotation

12) Max. working radius: 18 m

13) Ladder load: 800 kg

14) platform load: 360 kg

15) The opening time of outriggers: less than 30S

16) Arm operating time: less than 90S

17) Swing speed: 0-2r/min

19) Monitor flow: 950-4800 l/s in 0.55MPa

20) Monitor reach: more than 60m

Company Scane

HuBei ChengLi Special Automobile Co., LTD is a manufacturing group located in SuiZhou City, HuBei Province,China. SuiZhou is near to wuhan, Xiangfan and Shiyan,with these cities, there is a Golden Car Manufacturing hallway along the 318 highway. Among that, SuiZhou is famous as the capital of Chinese special automobile manufactory.

Since being founded in 1998, ChengLi has continually worked to improve its production processes and production tools. Qualified personnel ensure the highest standards of quality control in the manufacture of the principal components and the final assembly. Covering an area of 8 hectares more than 5000 vehicles are produced each year. Our company has independent export right, the product had delivery to many countries around the word. Take 2008 for example, the amount of export reach 2000 units. The registered Labels CLW is well known in these years.

Based on high quality and advanced technology, the leading varieties include more than 200 types of trucks such as water truck, garbage truck, fecal and sewage suction truck,refuse compactor, fuel tank, aerial platform, truck with crane, dump truck, van truck, trailers, fire-fighting truck, refrigerator truck, tractor, bulk cement truck, chemical liquid truck, concrete mixer truck, LPG tank, etc. All products have passed the ISO9001-2000 and t 3C(China Compulsory Certification) standard.

Company certification

ompany pass  the 3 c certification, BV certification, iso9000 quality system certification, environmental quality certification, SGS certification, and products.At the same time the company has also issued by the national government contract and credit enterprise certification, as well as issued by the bank credit enterprise, credit enterprise and user vote through the network.

Other problem

No.1 Payment

    We only Accept T/T  or Western Union;(30%as deposite, after Inspectiing at our factory ,pay the blance 70%) If you don't accepet, We sincerely welcome you to our factory for inspecting or discussing

No.2 Packing

Nude, Covered with max, small type can be put into 20"GP,or 40GP,40HQ,big type can be carried by bulk ship or RO-ROshipping or according to your requirement

No.3.Delivery Time

We have lots of truck in stock, delivery time is 7-15days as long

Remarks :

 The above Infomation is just for your reference.We can manufacure the truck as eachyour request.

Any questiones, pls feel free to reach me ,It would be great pleasure to be on your service.

Pls see below contact information or scan two-dimensional code
