Automatic 3 colors woven bag cutting sewing printing collecting processing machine line
Performance and Characteristics:
Performance and Characteristics
1.It's full automatic machine for making colorful pp woven sack.
2. It's contain material feeding, pp woven bag cutting in fixed length, printing and finished bag stacking, it's full automatic, only 1 person in operating and checking, save so much labor.
3. It adopts touch screen, PLC for controlling,servo motor for driving in order to control the length of sack precisely.
4. The mouth of the bag will be easily open and won't be conglutinated after heat cutting.
5. With Pneumatic loading,easy operating.
6. The auto cutting and printing machine can print sack from 1 color - 6 colors in one side or both side .
Max.Diameter of cloth roller(mm) | 1200mm |
Max.cutting width(mm) | 800mm |
Cutting leigth(mm) | 600-1200mm |
Cutting precision(mm) | ±4mm |
Folding width(mm) | 20-30mm |
Production capacity(pcs/min) | 30-40 |
Gross power(kw) | 6kw |
Weight(kg) | 2500kg |
Outline size (LxWxH)(mm) | 5100x2500x1200mm |
Sewing unit | Japanese NEW LONG or China best brand |
Inverter | Delta 1.5KW 2 set |
Pre-sales services
* Any concerns of our machine by email/phone will be replied ASAP within 24 hours
* Inquiry and consulting support
* Sample testing support
* View our factory
After-sales service
*Traning how to install the machine ,tranning how to use the machine
*Engineers are avaiable to service machinery overseas
*One year guarantee for the machine expect the spare part ,we can supply lifelong technology service to slove any problem form you .
1. Q: Are you a factory or trading company? How many people work in your company?
A: We are a factory .Wenzhou Ebey machine manufacture co.,ltd is a professional maufactuer of rope making machine line to make different kinds of rope ,auto cutting and sewing machine for pp woven sack,printing machine ,reycling machine etc and now we have more than 100 years till this year .
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Wenzhou City, Zhejiang Province, China, about 10 minutes from Aojiang train station and 1 hour from Wenzhou airport. It’s very convenient.
3. Q: Why choose us ?
A: Ablity: we are the first company who realize full automatic system on rope production line (contain yarn making machine ,twisting machine and rope making machine etc .) in China.
4. Q: How does your factory do regarding quality control?
A: Quality is priority." We always attach great importance to quality controlling from the beginning to the end. We have our own R&D department for researching new technology and improve machine .Our factory has passed ISO9001:2000 and we have got CE certificate for our machine .
5. What's your machine's after service ?
A: We have very good after sales service: After you purchase our machine we will send our engineer to your factory to install the machine and train your worker.But our machine is easy to operate ,because our machines are full automatic control by PLC and touch screen ,normally don't need our enginner to install and debug the machine ,it can save much time and money.
