System Summary
General control system is a kind of intelligent control system that corresponds with the lighting control of hotel lighting, building lighting and other indoor and outdoor scenes,the whole design scheme is based on humanized operation and personal principles. Each part of the system can work both independently control and set up various combinations of logical relationships in order to achieve a wide range of centralized and decentralized control; Through the computer network of the whole system monitoring, detection of the various lighting subsystem, achieve linkage control with Dali system, DMX system, control system, RS-485 bus and TCP / IP, and can be extended to intelligent control of the entire home or commercial systems.
Product name: 4 CH 20A EXP Rail led Switch Controller DMX 512 Control System Model No.: LYE410D
Switch Controller(4/8/12CH)
Model:LYE410D
Model:LYE810D
1. Technical Parameters:
Working temperature: -20-60℃
Power: AC100-240V
Output: 20A/CH
Protocol: GCY/DMX-512
Dimension: 186 * 92.6 * 61mm/275 * 92.6 * 61mm/365 * 92.6 * 61mm
Installation method: 35mm guide rail
Signal connector: 4 pin green terminal
2. Features:
1. Magnesium alloy casing, anti-static, anti-electrical fire, longer life.
2. Rail installation, simple operation, friendly interface.
3. Each device can be directly set the scene, the timing, zoning, no external equipment.
4. Built-in power, each device independently run offline.
5. Set to open multi channel delay time (0.1-10 seconds) / off, prevent the current impact.
6. Up to 99 zones, applicable to all types of places.
7. Each channel can be a separate mandatory switch and intelligent control.
8. External control panel, work independently or synchronously function.
The competitive advantage of product line:
/en/
Leyview (Shenzhen) Intelligent control co., Ltd. is a lighting control system and intelligent products based brand company, committed to the development and production of control system, to provide professional lighting control systems and solutions. In the field of intelligent control to their own core technology, build Leyview brand.
We always adhere to the "brand management as the core" concept, customized new sales model, management and price system; Adhere to the "mutual benefit and win-win" approach and long-term friendly cooperation between distributors, application in such a way, consistent brand building.
Leyview is a group of geese flying in the sky, we share a common goal, with the help of along the way with each other better forwarder the flight.
Question 1: Are you a factory or a trading company?
Answer: We are a factory.
Question 2: What's the main business of Leyview?
Answer: Leyview committed to the development and production of control system, to provide professional lighting control systems and solutions.
Question 3: What' s the main products of Leyview?
Answer: We focused on streetlight lighting control system(Zigbee/PLC/RS-485), general control system(DMX) and commercial lighting control system(DALI).
Question 4: What Leyview will do if we have problems after receiving your products?
Answer: Our products have been strictly inspected before shipping. Once you receive the products you are not satisfied, please feel free to contact us in time, we will do our best to solve any of your problems with our good after-sale service.
Question 5: How about your sales model?
Answer: We establish the brand as the foundation, with the constant expansion of the brand influence, distributors will replace the ordinary sales model of the market as our main sales channels.
