Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner

Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-1
Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-2
Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-3
Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-4
Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-5
Used for Grain Grading and Moving Stones Cleaning Machine Gravity Grade Destoner photo-6
US$ 4,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
HUALIANG
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Guangzhou Tianjin Dalian Shenzhen Nanjing Alataw Pass Manchuria Erlian port etc.
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name HUALIANG
Model Number TQSF200a
Production Capacity 18~30 T/H
Voltage 380V
Power(W) 2*0.75KW
Weight 1120KG
Dimension(L*W*H) 1660*2620*2156mm
Certification ISO9001
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Used for grain grading and moving stones cleaning machine gravity grade destoner



   RANGE OF APPLICATION



     TQSF-series gravity grade destoner is mainly used for grading wheat, rice, peanuts, corn, soybean, etc and removing stones, which can also be used for seed selecting. The machine has the characteristics of removing stones and sands according to classification, less energy consumption, no dust, lower noise, which can be operated and maintained conveniently. Use it together with independent ventilation system for better efficacy.



   MATERIALS OF GRAVITY GRADE DESTONER



a. The four corners are supported by imported “Austria” rubber springs, with reasonable stable structure.

b.  Vibrating motor adopts famous brand “Baofei” motor.

c. Stainless steel screen to remove stones and manganese screen surface to remove impurities are adopted.

d.  The lower screen adopts punched reinforcement aluminum mesh to make the screen surface more smooth and remove stones effect more better.





   TECHNICAL SPECIFICATION



Types

TQSF100a

TQSF125a

TQSF150a

TQSF180a

TQSF200a

TQSF250a

Screen width(cm)

100

125

150

180

100*2

125*2

Weight (kg)

630

690

750

900

1120

1250

Wind pressure (Pa)

1800

1800

1800

1800

1800

1800

Vibration frequency S-1

15.65-1

Output

(t/h)

Wheat

Paddy

Corn

13~15

9~11

8~10

15~18

11~13

10~12

17~22

13~15

12~14

22~28

16~18

15~17

25~30

18~22

16~20

30~36

22~26

20~24

Dimension

(L*W*H)

1660*1426*2156

1660*1676*2156

1660*1926*2156

1660*2226*2156

1660*2620*2156

1660*3120*2156

Power (kw)

2*0.55

2*0.55

2*0.55

2*0.55

2*0.75

2*0.75

Air volume (m³/h)

8100

12000

16000

20000

8100*2

12000*2

Vibration amplitude

3~5mm

Screen obliquity

5~9 degree





   PRODUCT PICTURES

 Used for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destoner



   SUCCESSFUL CASES

 Used for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destonerUsed for grain grading and moving stones cleaning machine gravity grade destoner



   COMPANY INTRODUCTION



    Luohe Hualiang Machinery is a professional manufacturer for cleaning equipment, dedusting equipment, powder cleaning device, washing equipment, lifting and conveying device and so on several series, with 14 years collect history. We have 10 production lines, 20 technicians, professional sales and after-sales teams and produce nearly hundred kinds of equipments.

   OTHER PRODUCTS



   PACKAGING

Used for grain grading and moving stones cleaning machine gravity grade destoner



   OUR SERVICES



    We provide a turnkey project of flour machinery, including special design, installation, commissioning and training workers.

    All of our new equipment to contain one year free spare parts, and quality guarantee period of one year.

    At the same time our company will carry on the lifelong service to our products.



   FAQ



Q1.In addition to clean wheat, what it can also be used to ?

A: It not only can be used to clean wheat, can also be used to grade rice, peanuts, corn, soybean, etc and removing stones , which can also be used for seed selecting.



Q2: How do i choose the machine model?

A: You should based on your washing products type and its output. Meanwhile we have professional pre-sales service personnal to help you find the most suitable product model.



Q3: If the machine fails to work, what should i do?

A: Don't worry. All of our new equipment to contain one year free spare parts and quality guarantee period of one year. At the same time, we will carry on the lifelong service.



Q4: Our staffs can't operate the machine, what can i do?

A: Our technicians will carry on training cuatomers' staffs until they can skillfully operate the machine. At the same time, will teach them some methods to solve the common faults of machines and daily repair and maintenance methods.
