Small Mobile Hammer Crusher
- TIANJIN OR QINGDAO
- T/T
You May Like
Product Details
| Condition | New | Type | Hammer Crusher | |
| Application | ore,mining,construction | Motor Type | AC Motor | |
| Power(W) | 7500 | Capacity(t/h) | 5-8 | |
| Place of Origin | Henan, China | Brand Name | DY | |
| Model Number | PC400*400 | Dimension(L*W*H) | 844*942*878 | |
| Weight | 0.9t | Certification | CE,ISO9001:2008 | |
| Warranty | 12 months | After-sales Service Provided | Engineers available to service machinery overseas |
small crushing equipment:Plywood case, wooden case or according to customer's requirement
Product Description
After entering into the crusher, the materials are attacked by the high speed hammers, and hit to the adjustable dental plate, to be primary crushed, the plate are located in the crusher entrance, and with super wear-resistance. Then the similar size entering into the main crushing cavity, to be secondary crushed. After secondary crushing, the material are attacked by the hammers again, regain kinetic energy, highly hit to impact liner plate (toothed). The materials are crushed again and again, between the liner plate, the hammers, the material themselves. Then the fine materials are discharged from discharge hole, being the final-products. The final size can be adjusted according to the space, between rotor and the liner plate.
1.It is widely used in water and electricity, expressway, sand and stone, crushing fields;
2.The crusher have low price,simple structure, reliable operation and convenient adjustment of discharging opening;
3.The overall design beautiful shape, compact structure, less wearing parts, easy maintenance, etc., is upgrading of products. Door crushing medium hardness materials, such as limestone, slag, coke, coal and other materials in the debris, crushing operation;
4.It can crush the wet stone, that is to say, you can wet the stone when crushing it to reduce the dust pollution, and keep the workers health and the good environment;
5.The hammer plate is made of high toughness material, through bead weld technical; make the surface much more wear-resistant.
| Model | Rotor speed (r/min) | Feed opening size (mm) | Max feeding size (mm) | Discharghing size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Overall dimensions L×W×H (mm) |
| PC400*400 | 1500 | 145×295 | 100 | 0-30 | 5-8 | 7.5 | 0.9 | 844*942*878 |
| PC600*400 | 1000 | 295×450 | 100 | 0-35 | 10-12 | 18.5 | 1.5 | 1000*1000*1300 |
| PC600*600 | 1000 | 295×570 | 100 | 0-35 | 12-18 | 45 | 2.14 | 1315*840*1501 |
| PC800*600 | 1000 | 350×570 | 120 | 0-45 | 20-25 | 55 | 2.45 | 1515*2586*1040 |
| PC800*800 | 1000 | 350×850 | 120 | 0-45 | 35-45 | 55 | 3.05 | 1515*2831*1040 |
| PC1000*800 | 1000 | 580×580 | 200 | 0-45 | 25-40 | 110 | 6.5 | 3206*2210*1515 |
| PC1000*1000 | 1000 | 580×1060 | 200 | 0-45 | 40-80 | 132 | 7.59 | 3514*2230*1515 |
| PC1250*800 | 750 | 650×850 | 200 | 0-45 | 20-50 | 132 | 11.7 | 2630*1780*2050 |
| PC1250*1250 | 750 | 650×1330 | 200 | 0-45 | 90-110 | 185 | 13.2 | 2630*2180*2050 |
| PC1400*1400 | 750 | 1050×1540 | 250 | 0-45 | 120-170 | 280 | 17.2 | 2790*2800*2310 |
| PC1600*1600 | 600 | 1500×1785 | 350 | 0-60 | 220-280 | 450 | 22.8 | 3350*3120*2660 |
Dayong impact hammer crusher can be applied for coal, coal gangue, coal cinder, lime, coke and other materials broken. Especially suitable for pulverized coal boiler, industrial boilers, boiler, such as circulating fluidized bed boiler. Widely used in thermal power, chemical, coal, metallurgy, building materials and other industries.
In order to give you a responsible quotation, you can inform us the following information:
1). What's the material you are going to deal with?
2). What's the granularity of the material?
3). What's the granularity of the final products are you going to achive?
4). What's the producing capacity you are going to achieve?
Our engineers will suggest you the most suitable one for you according to your information
Our company is the manufacturer which manufacture the vibration equipment,crusher,conveyer and other mining equipment for many years.Our company is a new-type shareholding system company which combines several decades of manufacturing experience and modern technology together.Dayong vibration equipment for many years the vibration of the manufacturing machinery, mining machinery throughout the country.
We can supply OEM and looking forward to your inquiry.
If you are interested in our products,pls email or call us.
Cell/Whatsapp:86-15637331601 Fax:86-373- 3669006
Skype:live:marydayong QQ:2847891973 WeChat:15637331601
Welcome to visit our factory and look forward to your cooperation.
Company Profile
Dayong Vibration Equipment Co. , Ltd. is a professional manufacturer of mechanical vibration of the professional design, development, manufacture which is also the first domestic production of vibrating screen equipment manufacturers. At present we have established a long-term cooperative partnership with the United States, Germany, Turkey, Indonesia, Tunisia and other countries. The DY series we produced ultrasonic screening machine, CNC standard test sieves widely used in food, medicine, chemical industry, metallurgy abrasives, plastics, glass, paint, nuisance processing. Our products have a wide range of application, screening accuracy, large handling capacity, long service life advantages compared with their peers. We have 65 experienced R & D personnel, We can offer different products to meet your needs. Our company has a superior geographic position and rich traffic. It takes about over one hour away from the Xinzheng airport . Welcome friends come to visit. Let the world is not difficult screening material!
