Help CenterConveying Phosphate Food Ingredients Bucket Elevator Equipment
Related Products
-
Reliable Quality v Belt Conveyor With Iron Remover RCYB-8US$ 2,000 - 4,000MOQ: 1 Set -
ABS Hopper Z Shape Bucket Elevator for FoodUS$ 1,500 - 60,000MOQ: 1 Set
-
Carbon Steel Horizontal Vibrating Screen for SandUS$ 500 - 10,000MOQ: 1 Set
-
Inclined Bag Loading ConveyorUS$ 200 - 1,000MOQ: 1 Set
-
Engineers Available to Service Machinery Overseas Grain Screw Conveyor Stainless Steel PriceUS$ 600 - 6,000MOQ: 1 Set
Welcome to XinXiang Dayong Vibration Equipment Co.,Ltd.
This is sunny, what can I do for you?
15 Years specializing in providing Top quality Machinery for you
Always on the way to do better
We are a leading and experienced Manufacturer and exporter in China with kinds of vibrating sifter equipment
(such as rotary,linear,circular and horizontal),filter machine; conveyor equipment and crusher equipment, etc.
If you are interested in these products, lend me a chance providing service for you.
|
Free to provide solution
|
Alibaba Trade Assurance
|
|
18 months warranty
|
0 risk purchase
|
All kinds of transfer type available
Belt tppe bucket elevator
Vertical vibrating bucket elevator
Chain type bucket elevator
Plate chain bucket elevator
What industry are you in?
Dayong help you choose the suitable machine
Your output benifit > Your input investment
Features:
1.The chains are bush roller; chain,discharge by gravity, suitable for the vertical lifting of various powder and lumps materials;
2.For the bush roller chain conveyor, induction of gravity discharge, for a variety of powder, bulk material to enhance the vertical material;
3.The shell uses fold beading cabinet, all welded chassis, good sealing performance, the overall rigidity of strength, environmental;
4.Equipped with explosion relief port, prevent dust explosion, safe and reliable;
5.Feeding could be in both shaft-end and upwards direction;
6.Optional with off-tracking alarm and speed monitor system.
Technical parameters :
| Model | convey capacity(m³/h) | Hopper capacity(L) | Hopper dimension(mm) | Single chain breaking strength (KN) | moving speed(m/s) | rotating speed(r/min) | Max block(mm) |
| 160 | 19 | 1.2 | 350 | >170 | 1.3 | 62.5 | 20 |
| 250 | 30 | 3 | 450 | >320 | 1.3-1.4 | 1.3-1.4 | 20-35 |
| 315 | 35 | 3.75 | 512 | >320 | 1.4 | 42.5 | 35 |
| 400 | 58 | 5.9 | 512 | >320 | 1.5 | 37.6 | 40 |
| 500 | 73 | 9.3 | 688 | >480 | 1.5 | 35.8 | 50 |
| 630 | 114 | 14.6 | 688 | >480 | 1.6 | 31.8 | 60 |
| 800 | 150 | 24 | 936 | >560 | 1.6 | 30.5 | 75 |
| 1000 | 240 | 38 | 936 | >560 | 1.6 | 30.5 | 75 |
| 1250 | 360 | 60 | 1001 | >660 | 1.6 | 28 | 100 |
To choose the suitable model, please tell us:
- Name and feature of the raw material?
- conveying height you want?
- Handling capacity: kg /h, L/h
Note: You had better send us the relevant pictures about the details.
Design & production
|
Professional design teamEngineer provide suitable design Provide the best solutions before production 100% personal production |
|
Strict inspection principle
|
Strict inspection procedure
|
Note: You had better send us the relevant pictures about the details.
11 years engaged in machinery production
65 experienced R & D personnel to provide technical guide
Certification supporting
Standard production workshop
Professional sales team
Tips: If you want to know our product details, please check the following website:
or
Reated products
|
|
Welfare for customer
Former customer have the priority of coupon.
customers will get spare parts gift after provide the site operation video.
1).MOQ require?
- Our moq is 1 set.(If you need the spare parts,it is also ok).
2).Payment method?
- Usually,we accept T/T,Western Union and others, we can't accept D/P,D/A
3).How to guarantee the quality?
- If any machine quality problems, we accept return cargos.
- Our warrantity is 18 months, promise your 0 risks purchasing
4).Packing and Delivery
- Standard export wooden case to protect the machine from demage.
- If we have no stock, we will delivery within 7-20 working days.
More details, Please contact us.
|
Contact: sunny Phone/Whatsapp: 008615090442314 |
|
