Vibrator Shaker Screen for Pepper

Vibrator shaker screen for pepper

Round Separator :

(1) High efficiency, refined design, duration, any powder and mucilage are suitable for sieving.

(2) Easily to replace the net, simple operation and convenient washing.

(3) Never clog the mesh, no powders fly up, minimum sieving size is 500meshes or 0.028mm.

(4) Discharge the impurity and coarse materials automatically, and continuous operation.

(5) Unique net-frame design, long life for using, only need 3-5 minutes to replace the net.

(6) Small volume, move easily.

(7) The most layers of the sieve are about 5, but 3 are suggested.

brief description:

The round separator is a universal device designed with full demonstrability and utmost optimization and have the tend to be standardized. It is very suitable to separate small particle, minuteness powder and the separation of solid and liquid.

1.     This round separator is one of precised powder sieve,it is of high efficiency,and the screening exceeds 90%.

2.     It adopts whole sealing structure design,the sealed effect is fairly well,no dust pollution,no leaking liquid,no material left in machine,and no dead angle in the net frame.

3.     Small volume and light weight,easy to be installed and maintained.

4.     The outlet can be adjusted at any angle,and it is easy to replace the screen.

5.     the rubber ball device can reduce the changce of jam on the screen.

6.     By adding the device ultrasonic instrument conversion device,  superfine materials up to 600 mesh can be sieved.

Scope of application:

It is widely used in many industries, such as mining,building,materials,metallurgy,casting,abrasive,chemical,light industry,medicine and food industry.

Principle of the structure.

It uses vertical motor as the source of vibration, with eccentric hammer on the both sides of motor ,change circumrotate to level ,upright and incline movement,then pass these three movement to surface of the screen. Adjust the phasic angle on the both sides of the top and bottom to change the movement track of the surface screen. This will help to screen different materiel in different situation successfully.

Specification and installation:

1.There are eight Specifications for this S49-B series round separator, materials using in each part can be customized .

2.Pls confirm the voltage and if the motor request for explosion-proof .

3.we can also accept special orders.

The  structure of our product

The details of our product
