Vibrating Screen for Sand Sieving and Grading

Vibrating Screen for Sand Sieving and Grading photo-1
Vibrating Screen for Sand Sieving and Grading photo-2
US$ 2,000 - 4,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Goafu
Model Number:
SZF series
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin / Shanghai / Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name Goafu
Model Number SZF series
After-sales Service Provided Engineers available to service machinery overseas

Vibrating Screen for Sand Sieving and Grading



 Vibrating Screen for Sand Sieving and Grading

Vibrating Screen for Sand Sieving and Grading



Introduction



Linear vibrating screen is generally used to sifting the material of non-sticky and dry powder , 0.074-5mm size, less than 70% moisture content, etc. Maximum feed particle size is not more than 10mm.







It is made up of vibrating motors, screen box, hopper, vibration damping springs and the support. Thesurfaceof linear vibrating screen can be inclined installed, and the inclination angle is 10°~15.







Vibratory screens can be provided with dust proof cover as required. ZS Series linear vibration screen can be supplied of different sizes depending upon capacity required. They can also handle slightly wet material.







Applications



1) For screening&grading of dry powder, fine particle and fine powder.



2) Widely used in abrasive, building material, ceramic, chemical,  fertilizer,  food,  plastic, pharmaceutical, metallurgy industries, etc.







Characteristics



1)This machine is used for the coarse screening with large production output.



2) Long residence time of the materials on the screen net brings a large processed quantity.



3) The inclination of the screen surface can be adjusted to balance the screen accuracy and the production output.







Notice



Please provide us the following requirement, we will select suitable vibrating screen for you.



(a) The name of materials



(b) Aim of using: get rid of impurity, filtration, grading



(c) Treatment volume: kg /h, L/h.



(d) The specification of screen (mesh or mm).



(e) How long is the operation time every day?



(f) Vibratory screen can be provided with dust proof cover as required



Technical Data





Model

Size(mm)

Inclination

Amplitude(mm)

Layer

Power(KW)

SZF-520

500×2000







0-7 degree







4-10







1-6 layer

2*(0.4-0.75)

SZF-525

500×2500

2*(0.4-0.75)

SZF-1020

1000×2000

2*(0.4-0.75)

SZF-1025

1000×2500

2*(0.4-1.1)

SZF-1030

1000×3000

2*(1.1-1.5)

SZF-1040

1000×4000

2*(1.1-1.5)

SZF-1235

1200×3500

2*(1.1-2.2)

SZF-1250

1200×5000

2*(1.1-2.2)

SZF-1535

1500×3500

2*(1.1-2.2)

SZF-1560

1500×6000

2*(2.2-3.7)

SZF-1845

1800×4500

2*(2.2-3.7)

SZF-2050

2000×5000

2*(2.2-3.7)

SZF-2260

2200×6000

2*(2.2-3.7)





Note:



1. Each type can be 1-5 layers, and the mesh size is from 0.1 to 30mm.

 2. Material: Q235A / SUS 304 / 316L

 3. Voltage: 380V /400V, Frequency: 50 / 60 HZ.



Our Screen frame has two types:  different screen frame structures, help you get more quality screening purpose!



Type 1. Stainless steel screen frame



Vibrating Screen for Sand Sieving and Grading



Type 2. wooden screen frame



Vibrating Screen for Sand Sieving and Grading



The results of the screening process :Big, small, the smallest size.

 Vibrating Screen for Sand Sieving and Grading

Our vibrating sorter are ready for pakage.



Vibrating Screen for Sand Sieving and Grading





    GAOFU company have a perfect after-sales service system and professional technology team to provide you with prompt and thorough service. Our price are more competitive and reasonable, each order will be supplied within the stipulated period.

 Vibrating Screen for Sand Sieving and Grading



all types of Linear vibrating screen
