Rubber Conveyor
Belt conveyer is a kind of machine that to transfer the material continuously. The belt works under the effect of frictional force. It is not only the components to transfer the material, but also the components to transfer the force.
The belt conveyer is advanced and simple in structure, easy to maintain. Its transfer capacity is high, transfer distance is long. They are widely used in mining, metallurgical and coal industry to transfer sandy or lump material, or packaged material. In many situation, it Is a very important component of nonstandard machinery.
The conveyers consist of standard parts, which are advanced and simple in structure, easy to maintain. They are widely used in mining, metallurgical and coal industry to transfer sandy or lump material, or packaged material. According to different transferring equipment, the transfer system can be one independently or multi-conveyers or combined with other transfer equipments. The belt conveyer can be installed horizontally or aslope to meet the needs of different transfer lines.
Working principle
The motor drives the driving rollers of the belt conveyor, and drives the roller by the strong belt advances. Materials are conveyed from the original place to the place where they are needed.
The belt conveyers can be operated in the circumstance temperature range from -20°C to +40°C. The temperature of transferred material by this belt conveyer should be lower than 50°C.
Technology parameters
Belt Width(mm) |
Belt Length (m) / Power (kW) |
Belt Speed (m/s) |
Capacity (t/h) |
||
500 |
≤12/3 |
12-20/4-5.5 |
20-30/5.5-7.5 |
1.3-1.6 |
45-100 |
650 |
≤12/4 |
12-20/5.5 |
20-30/7.5-11 |
1.3-1.6 |
70-120 |
800 |
≤10/4 |
10-15/5.5 |
15-30/7.5-15 |
1.3-1.6 |
120-180 |
1000 |
≤10/5.5 |
10-20/7.5-11 |
20-40/11-22 |
1.3-2.0 |
160-250 |
1200 |
≤10/7.5 |
10-20/11 |
20-40/15-30 |
1.3-2.0 |
200-400 |
Customer site
Our Company:
Our company has more than 30 years experience in machinery manufacturing industry , so We can provide you professional free technical service.
We ever exported this machine to America , Australia , Canda , Chile , Trinidad , and Tobago , Peru , Ghana and so on .And the perfect quality of the machine acquire many my customers` great praise .
Our company has passed the ISO9001:2008 Quality system certificate , and obtained the CE certificate.
