Microwave industrial mushroom dryer and sterilizer/ fungus drying machine and sterilization machine
- 50 Set / Sets per Month
- Qingdao Shanghai Ningbo Guangzhou Shenzhen or others
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | BODA or OEM |
Model Number: | BDMD-F-P-30 | Type: | Other, dryer and sterilizer | Voltage: | 380v |
Power(W): | 30kw | Weight: | 2500 | Dimension(L*W*H): | 8.0x1.1x1.7m |
Certification: | CE, ISO | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Microwave industrial mushroom dryer and sterilizer/ fungus drying machine and sterilization machine
Model number | BDMD- F-P-30 |
Description | BODA microwave drying and sterilizing machine for mushrooms and fungus |
Microwave frequency (MHz) | 2450±50 |
Input voltage | 380V, 50Hz |
Microwave power(KW) | 30kw |
Chamber material | Stainless steel |
Chamber color | Silver-white |
Conveyor belt | Teflon or stainless steel mesh belt |
Mushroom dryer dimension(L*W*H)(mm) | 8.0x1.1x1.7 |
Weight (KG) | 2500 |
Microwave leakage limit(mW/cm2) | 1 mW/cm2 |
Relative humidity(℃) | ≤85% |
Ambient temperature(℃) | Normal temperature |
Environment requirement | No excessive corrosive gas, no inflammable, explosive gas |
Mushroom dryer and sterilizer Model | Microwave frequency (MHz) | Microwave power | Microwave leakage | Dimension (m) | Installation area (m) |
BDMD-F-P-20 | 2450±50 | 20kw | 1mW/cm2 | 7.0x1.1x1.7 | 9x3.5x2.5 |
BDMD-F-P-30 | 2450±50 | 30kw | 1mW/cm2 | 8.0x1.1x1.7 | 10x3.5x2.5 |
BDMD-F-P-40 | 2450±50 | 40kw | 1mW/cm2 | 9.0x1.1x1.7 | 11x3.5x2.5 |
BDMD-F-P-50 | 2450±50 | 50kw | 1mW/cm2 | 10.0x1.1x1.7 | 12x3.5x2.5 |
BDMD-F-P-60 | 2450±50 | 60kw | 1mW/cm2 | 11.0x1.1x1.7 | 13x3.5x2.5 |
BDMD-F-P-70 | 2450±50 | 70kw | 1mW/cm2 | 12.0x1.1x1.7 | 14x3.5x2.5 |
BDMD-F-P-80 | 2450±50 | 80kw | 1mW/cm2 | 13.0x1.1x1.7 | 15x3.5x2.5 |
BDMD-F-P-100 | 2450±50 | 100kw | 1mW/cm2 | 16.0x1.1x1.7 | 18x3.5x2.5 |
BDMD-F-P-120 | 2450±50 | 120kw | 1mW/cm2 | 18.0x1.1x1.7 | 20x3.5x2.5 |
BDMD-F-P-150 | 2450±50 | 150kw | 1mW/cm2 | 21.0x1.1x1.7 | 23x3.5x2.5 |
BDMD-F-P-200 | 2450±50 | 200kw | 1mW/cm2 | 27.0x1.1x1.7 | 29x3.5x2.5 |
Microwave mushroom dryer and mushroom sterilizer will be custom designed according to the materials, process quantity, factory space and other requirements.
Usage:
The mushroom/fungus microwave dryer and sterilzer is used for the drying and sterilization of mushrooms, fungus, fruits and vegetables, spices and seasonings, etc.
The microwave dryer and sterilizer can dry and sterilize at the same time.
Advantage:
Microwave mushroom sterilizer and mushroom dryer has a number of quantitative and qualitative advantages over conventional steam retorting because of the relatively short heating time and uniform volumetric heating, potential to produce high quality self-stable food products. The mushrooms dried or sterilized by microwave dryer & sterilizer will greatly improve sensory, apperance and nutritional value, and dramatically extend the shelf life.
One main advantage is the place where the heat is generated, namely the product itself. Because of this, the effect of small heat conductivities or heat transfer coefficients does not play such an important role. Therefore, larger pieces of mushrooms can be dried or sterilized in a shorter time and with a more even drying and sterilization effect. These advantages often yield an increased production.
- Energy saving 30%-60%
- Mushroom sterilization speed 50% quicker
- Reduced CO2 emissions
- Increased manufacturing efficiency and throughput
- Drying and Sterilization temperature of different mushrooms adjustable
- Suitable for mushroom and fungus drying and sterilizing
- Patent core components of mushroom drying machine and mushroom sterilization machine manufactured by BODA, reliable and stable performance.
- Machine chamber is made with stainless steel of food grade, smooth appearance, easy for clean and maintain.
- Adopting PLC system and Monitor screen, easy to operate and control whole drying and sterilization process.
- Adopting unique sealing technology, non-leakage.
- Adopting advanced temperature measuring technology, ensuring the accuracy of temperature control easily.
- Adopting advanced oil cooling and water-cooling/air-cooling technology, high efficiency and extends service life of electric components.
- Conveyor auto deviation-checking device keeps the mushroom dryer and sterilizer running smoothly and steadily.
- Adopting reasonable layout for generator tubes, all objects on conveyor belt absorbing same microwave energy to ensure the same drying rate.
- Microwave power, conveyor speed, drying temperature are adjustable.
Soft packing is supplied.
Wooden case packing will be provided to Microwave mushroom dryer or mushroom sterilizer if necessary.
For convenient installation, mushroom dryer and sterilizer will be shipped out as a whole.
BODA microwave dryer and sterilizer machine company provides a full range of services and technical support for industrial microwave drying and sterilization systems. The services include custom installations, preventive equipment maintenance, equipment upgrades and modifications and microwave drying and sterilzation system repair.
BODA microwave equipment company provides drying machine and sterilization machine for all kinds of foods, chemicals, pharmaceuticals, etc.
Microwave mushrooom dryers and sterilizers offer users a time saving, environmental friendly and effecient way than conventional machines. Microwave drying or sterilizing machines, microwave vacuum dryers, hot air dryers/steam dryers are the best selling machines. Oven type and tunnel type are available.
1. What is Microwave?
Microwaves are a form of electromagnetic energy with frequencies between 300 MHz and 300 GHz, generated by magnetrons under the combined force of an electric and a magnetic field perpendicular to each other.
2. What is the advantage of Microwave mushroom drying and sterilization machine compare to Conventional drying and sterilization machine?
Conventional drying and sterilization machine is a surface drying and sterilization method, which is not only slow, but also non-uniform with the surfaces, edges and corners of mushrooms or fungus. The imperfect drying and sterilization will cause product rejections, waste energy and extend process time.
Microwave mushroom dryer and sterilizer is a direct method of drying and sterilization. Energy is transferred through the material electro-magnetically, not as a thermal heat flux. Therefore, the effect of drying and sterilization is uniformity and process time is short.
Microwave mushrooms sterilizer and dryer could completely preserve the original color, fragrance, nutrition and other properties of spices.
3. How about safety?
Using scientific structure and patented suppression system, BODA industrial microwave mushroom drying machine and mushroom sterilization machine poses no threat of electromagnetic radiation to the health and safety of equipment operators.
4.What about maintenance?
In addition to downtime for cleaning and inspection, conventional sterilizers and heat exchangers need periodic servicing with an expensive inventory of parts and a highly trained labor force. For microwave dryer and sterilizer, the only part that requires maintenance is the magnetron. In the event of a malfunction or misuse through incorrect operation, this can easily be replaced in less than thirty minutes. Generally, BODA recommends that the magnetron of industrial microwave dryer and microwave sterilizer be replaced annually or after 8,000 hours of operation, whichever is sooner.
