10 ton electric remote command hoist

FOB Price

USD $600 - $1,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shandong, China
Brand Name	JNDO	Model Number	CD1
Usage	Construction Hoist	Power Source	Electric
Sling Type	Wire Rope	Maximum Lifting Weight	3 ton
Maximum Lifting Height	30M	Lift Speed	8/0.8
Certification	ISO	Warranty	1Year
After-sales Service Provided	No overseas service provided

10 ton electric remote command hoist

Product Description

Feature of 10 ton electric remote command hoist :

1. Tight structure ,smart body,safety and reliability ,commom-used parts,strong lifting capacity, easy maintance.

2. The hoists exists in form of stationary style and crab-style.

3. The products are widely at industrial ore enterprises ,railway,harbors,warehouses and materials sites etc.

4. Working environment:no fire,no explosive danger ,no corrosive media and no dirt exist.

5. Working temperature:-25°C~+40°C ,Wetness is less than 85%.

6. 380v/50Hz/3Phases

7. Mainly consists 3 parts:lifting mechanism ,traveling mechanism and electrical equipment

8. With slight modification.

Product Parameter

parameter of 10 ton electric remote command hoist

10 ton electric remote command hoist
Model	MD1 0.25T	MD1 0.5T	MD1 1T	MD1 2T	MD1 3T	MD1 5T	MD1 10T	MD1 16T	MD1 20T
Capacity t	0.25	0.5	1	2	3	5	10	16	20
Standard lifting height m	3--9	6--12	6--30	6--30	6--30	6--30	9--30	9--18	9--18
Lifting speed m/min	8/0.8	8 /0.8	8 /0.8	8 /0.8	8 /0.8	8 /0.8	7/0.7	3.5/3.5	3.5/3.5
Running Speed m/min	20	20	20	20	20	20	20	20	20
Wire rope type	6*9	D-6*37+1	D-6*37+1	D-6*37+1	D-6*37+1	D-6*37+1	D-6*37+1	6*37+1	6*37+1
I-beam track type	6-22b	16-28b	16-28b	20a-32c	20a-32c	25a-63c	25a-63c	45a-63c	50a-63c
Loop track minium radius m	0.8	1.5	1.5-4	2--4	2--4	2.5-5	2.5-9	3-4.6	3-4.6
Power supply	220V-440V,3phase,50-60HZ
Working duty	Mid M3	Mid M3	Mid M3	Mid M3	Mid M3	Mid M3	Mid M3	Mid M2	Mid M2

picture or product
