Home > Products > Crane accessories > 1t digital force electronic dynamometer
1t digital force electronic dynamometer
- 600 Set / Sets per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | electronic hand dynamometer |
Type: | Crane Scale | Power Supply: | 3pcs AA | Display Type: | 25mm 5digits LCD |
Rated Load: | 200T | Accuracy: | 0.5kg |
Product Description
Specifications
1t digital force electronic dynamometer1.used for a variety of purposes
asuring overhead loads, traction and the te
1t digital force electronic dynamometer
MODEL | A(mm) | B(mm) | C(mm) | D(mm) | φ(mm) | H(mm) | Material |
---|---|---|---|---|---|---|---|
DL-R-01 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
DL-R-02 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
DL-R-03 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
DL-R-05 | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
DL-R-10 | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
DL-R-20 | 420 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
DL-R-30 | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
DL-R-50 | 465 | 150 | 104 | 305 | 184 | 930 | Alloy Steel |
DL-R-100 | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
DL-R-200 | 725 | 265 | 183 | 440 | 280 | 1380 | Alloy Steel |
Specification of Wireless tension link:
MODEL | Max. capacity(kg) | Min. weigh(kg) | Division(kg) | Total dispay counts (n) |
---|---|---|---|---|
DL-R-01 | 1000 | 10 | 0.5 | 2000 |
DL-R-02 | 2000 | 20 | 1 | 2000 |
DL-R-03 | 3000 | 20 | 1 | 3000 |
DL-R-05 | 5000 | 40 | 2 | 3000 |
DL-R-10 | 10000 | 100 | 5 | 2000 |
DL-R-20 | 20000 | 200 | 10 | 2000 |
DL-R-30 | 30000 | 200 | 10 | 3000 |
DL-R-50 | 50000 | 400 | 20 | 2500 |
DL-R-100 | 100000 | 1000 | 50 | 2000 |
DL-R-200 | 200000 | 2000 | 100 | 2000 |
Description of wireless tension link
1.Rugged construction.
2.Accuracy: 0.05% of capacity.
3.All fuctions and units are clearly display on the LCD (with backlighting).
4.Digits are 1 inch high for easy distant viewing.
5.Two user programmable Set-Point can be used for safety and warning applications or for limit weighing.
6.Long battery life on 3 standard “LR6(AA)”size alkaline batteries.
7.All commonly used internationally recognized units are available : kilograms(kg), short Tons(t) pounds(lb), Newton and kilonewton(kN).
8.Infrared Remote control easier to calibration(with password).
9.Infrared Remote control with many fuctions : “ZERO”, ”TARE”,”CLEAR”, “PEAK”, ”ACCUMULATE” ,”HOLD” ,”Unit Change” ,”Voltage Check” and “Power OFF”.
10. local mechanical keys :”ON/OFF”,”ZERO”,”PEAK” and ”Unit Change”.
11.low battery warning .
Main technical data :
Display | 25mm (1’’) 5digits LCD |
Power on zero range | 20% F.S. |
Manual Zero Range | 4% F.S. |
Tare Range | 20% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥40 hours |
Battery Type | “LR6(AA)”size alkaline batteries. 1.5V*3 |
Operating Temp | - 10℃ ~ + 40℃ |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | 7AAA battery, 1.5V*2 |
We can provide not only amazing products,but also special ones designed at requests.We'll do our best to meet the need of customers.
