Home > Products > Crane accessories > OCS LED display digital weighing crane scale 20t
OCS LED display digital weighing crane scale 20t
- 10000 Piece / Pieces per Month
- Qingdao
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | OCS |
Type: | Hanging Scale | Power Supply: | Lead Acid 6V/7Ah | Display Type: | LED/LCD |
Rated Load: | 50t | Accuracy: | 0.2kg to 5kg |
Product Description
OCS LED display digital weighing crane scale 20t
Description of wireless crane scale :Wireless electronic crane scale is one kind of frequently-used weighing device and brings great convenience to people's work.
Features of wireless Crane sacle :
1.30MM(1.2'')LED display with readablity
2.High quality square die casting aluminum,sturdy and durable
3.With storing function for the present, it is convenient to record weight
4.Automatic dormancy/shutdown saving energy design
5.Weight accumulation and demanding function
6.Handheld remote control with operating easily and convenience
7.With adjusting acceleation factor of gravity, suitable for all over the world
8.Display adjsting of speed and shakeproof rank, with small error and calibration by hand
9.Independent battery box design, it is easy to replace battery
1.-Multi-weighing units:
Kg, lb, N are selectable, generally kg is the default unit.
2.-Multi-function operation:
Tare;Zero;Auto zero tracking;Total;Hold; Overload warning and record, operate through remote controller ,etc functions.
3.-User-friendly design:
Cast aluminium housing for maximum protection; Large red 5 digit LED display (digit height 30mm); Battery Operated with low battery indication; Automatic turn off , power-saving function.
specification of wireless crane scale
MODEL | Max. capacity(kg) | Min. weigh(kg) | Division(kg) | Total dispay counts(n) |
OCS-SL-2 | 2000 | 20 | 1 | 2000 |
OCS-SL-3 | 3000 | 20 | 1 | 3000 |
OCS-SL-5 | 5000 | 40 | 2 | 2500 |
OCS-SL-10 | 10000 | 100 | 5 | 3000 |
OCS-SL-15 | 15000 | 200 | 5 | 3000 |
OCS-SL-20 | 20000 | 200 | 10 | 2000 |
Standard | According to OIML class III |
Display | 30mm (1.2’’) 5digits LCD/LED |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥50 hours |
Battery Type | Fully sealed Lead-Acid battery, 6V/4.5Ah |
Adapter | DC9V/1000mA |
Operating Humidity | ≤85% RH under 20℃ |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | AAA battery, 1.5V×2 |
MODEL | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) | H(mm) | N.W.(kg) |
---|---|---|---|---|---|---|---|
OCS-SL-2 | 95 | 260 | 33 | 195 | 135 | 430 | 10.5 |
OCS-SL-3 | 95 | 260 | 40 | 195 | 135 | 455 | 11.5 |
OCS-SL-5 | 120 | 325 | 50 | 240 | 165 | 535 | 17.5 |
OCS-SL-10 | 124 | 325 | 60 | 240 | 165 | 660 | 27.5 |
OCS-SL-15 | 225 | 345 | 70 | 240 | 165 | 855 | 49 |
OCS-SL-20 | 225 | 345 | 85 | 240 | 165 | 920 | 56 |
wireless crane scale Photo Show:
Delivery: 10 days after received the order Packaging: carton or wooden industrial scale
