Home > Products > Crane accessories > Digital Mini Crane Weighing Scale Indicator
Digital Mini Crane Weighing Scale Indicator
- 1000 Piece / Pieces per Month
- QINGDAO
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | JNDO | Model Number: | OCS-SP |
Type: | Hanging Scale | Power Supply: | Lead Acid 6V/7Ah | Display Type: | LED/ LCD |
Rated Load: | 1000kg | Accuracy: | 0.02kg to0. 5kg |
Product Description
Specifications
Digital Mini Crane Weighing Scale Indicator1.Capacity:50kg-1000kg
2.Certificate: CE;ISO9001
Digital Mini Crane Weighing Scale Indicator
Wireless electronic crane scale is one kind of frequently-used weighing device and brings great convenience to people's work.
Features of portable Crane Scale :
1.30MM(1.2'')LED display with readablity
2.High quality square die casting aluminum,sturdy and durable
3.With storing function for the present, it is convenient to record weight
4.Automatic dormancy/shutdown saving energy design
5.Weight accumulation and demanding function
6.Handheld remote control with operating easily and convenience
7.With adjusting acceleation factor of gravity, suitable for all over the world
8.Display adjsting of speed and shakeproof rank, with small error and calibration by hand
9.Independent battery box design, it is easy to replace battery
MAIN TACHNICAL DATA:
Standard | According to OIML class III |
Display | 30mm (1.2’’) 5digits LCD/LED |
Zero Range | 4% F.S. |
Tare Range | 100% F.S. |
Stable Time | ≤10seconds |
Overload Indication | 100% F.S. + 9e |
Max. Safety Load | 125% F.S. |
Ultimate Load | 400% F.S. |
Battery Life | ≥50 hours |
Battery Type | Fully sealed Lead-Acid battery, 6V/4.5Ah |
Adapter | DC9V/1000mA |
Operating Humidity | ≤85% RH under 20°C |
Remote Controller Distance | Min. 15m |
Battery of Remote Controller | AAA battery, 1.5V×2 |
Parameters of portable Crane Scale
MODEL | Max. capacity(kg) | Min. weigh(kg) | Division(kg) | Total dispay counts(n) |
OCS-SP-005 | 50 | 0.4 | 0.02 | 2500 |
OCS-SP-01 | 100 | 1 | 0.05 | 2000 |
OCS-SP-02 | 200 | 2 | 0.1 | 2000 |
OCS-SP-03 | 300 | 2 | 0.1 | 3000 |
OCS-SP-05 | 500 | 4 | 0.2 | 2500 |
OCS-SP-1 | 1000 | 10 | 0.5 | 2000 |
Illustration of 1portable Crane Scale
MODEL | A(mm) | C(mm) | H(mm) | N.W.(kg) |
OCS-SP-005 | 33 | 24 | 320 | 4 |
OCS-SP-01 | 33 | 24 | 320 | 4 |
OCS-SP-02 | 33 | 24 | 320 | 4 |
OCS-SP-03 | 33 | 24 | 320 | 4 |
OCS-SP-05 | 41 | 25 | 345 | 4.2 |
OCS-SP-1 | 41 | 25 | 345 | 4.2 |
