Specifications
Suitable for various prepared foods, aquatic products and especially varieties unsuitable for fluidized freezingSeafood tunnel quick freezer, the best equipment for quick freezing all kinds of fruit and vegetable, and some of the seafood.
Adopts the two stage belting structure---firstly, quick-cooling step. Secondly, deep-freezing step.
Product features
1. The combination design of multidirectional air flow ensures high quality individual quick freezing products.
2. The conveying belt and fan adopt frequency conversion speed adjustment
3. Adopt the wide net belt or double plate belt
4. Providing with the high-efficiency cleaning device
Main technical parameters
|
Model Parameters |
SSD-300 |
SSD-500 |
SSD-1000 |
SSD-1500 |
SSD-2000 |
SSD-3000 |
Output±10%(kg/h) |
300 |
500 |
1000 |
1500 |
2000 |
3000 |
Refrigerating capacity(kw) |
70 |
130 |
186 |
256 |
330 |
550 |
Freezer length(m) |
8 |
9 |
11 |
13 |
16 |
28 |
Overall dimensions(m) |
10.4*3*2.5 |
12.4*3.6*2.5 |
14.9*3.6*2.5 |
16.9*3.6*2.5 |
19.9*3.6*2.5 |
31.9*3.6*2.5 |
Power required(kw) |
21.2 |
29 |
35 |
42 |
49 |
63 |
Input material tmpt(oc) |
+15 |
|||||
Output material tmpt(oc) |
-18 |
|||||
Tinside the freezer(oc) |
-36±2 |
|||||
Freezing time(min) |
12-100 continually adjustable |
|||||
Coolant |
R717/R22 |
|||||
