Help CenterVegatable and Fruit Tunnel Quick Freeze Machine for Sale
Related Products
-
Sanshon SSF Spiral Quick Freeze Machine, Industrial Freezer PriceNegotiableMOQ: 1 Set -
Sanshon Sweet Corn Quick Freezer MachineUS$ 50,000 - 175,000MOQ: 1 Set
-
Quick Frozen Processing EquipmentUS$ 55,000 - 58,000MOQ: 1 Set
-
Sanshon SSF Fruit and Vegetable Spiral Industrial Freezer UnitNegotiableMOQ: 1 Set
-
Industrial Food Quick Frozen MachineUS$ 30,500 - 69,000MOQ: 1 Set
Specifications
Suitable for various prepared foods, aquatic products and especially varieties unsuitable for fluidized freezingStrimp tunnel quick freeze machine, the best equipment for quick freezing all kinds of fruit and vegetable, and some of the seafood.
Adopts the two stage belting structure---firstly, quick-cooling step. Secondly, deep-freezing step.
Product features
1. The combination design of multidirectional air flow ensures high quality individual quick freezing products.
2. The conveying belt and fan adopt frequency conversion speed adjustment
3. Adopt the wide net belt or double plate belt
4. Providing with the high-efficiency cleaning device
Main technical parameters
|
/Model Parameters |
SSD-300 |
SSD-500 |
SSD-1000 |
SSD-1500 |
SSD-2000 |
SSD-3000 |
Output±10%(kg/h) |
300 |
500 |
1000 |
1500 |
2000 |
3000 |
Refrigerating capacity(kw) |
70 |
130 |
186 |
256 |
330 |
550 |
Freezer length(m) |
8 |
9 |
11 |
13 |
16 |
28 |
Overall dimensions(m) |
10.4*3*2.5 |
12.4*3.6*2.5 |
14.9*3.6*2.5 |
16.9*3.6*2.5 |
19.9*3.6*2.5 |
31.9*3.6*2.5 |
Power required(kw) |
21.2 |
29 |
35 |
42 |
49 |
63 |
Input material tmpt(oc) |
+15 |
|||||
Output material tmpt(oc) |
-18 |
|||||
Tinside the freezer(oc) |
-36±2 |
|||||
Freezing time(min) |
12-100 continually adjustable |
|||||
Coolant |
R717/R22 |
|||||
