double shaft shredder machine
Double Shaft Shredder machine is capable of handling the most difficult projects, and it is widely utilized in various fields. as an effective solution with the throughput which up to 3000kg/h.
It is always used for coarse shredding which is ideal for shredding big plastic barrel, circuit board, tyre, wood and plastic film to small pieces for easy reprocessing, storage and transportation, creating new value from reusable wastes.
double shaft shredder machine
double shaft shredder machine
The cutting discs on the rotor of the shredder are arranged in such a way that a cutting disc on one shaft is positioned between two cutting discs on the opposite shaft. As a result, the material is shredded both lengthways and crossways.
double shaft shredder machine
It featured with:
1 Heavy-duty construction and efficient performance are determined by the precisely processed combined frame made of extra-thick plates
2 Wide angle, hexagon prism of power slewing axis; Large hopper with big caliber for feeding large material
3 It adopts PLC control system, automatic overload protection and auto reverse switch
4 The low rotation speed results in a particularly quiet shredding process with low levels of dust generation
5 It can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc.
Double Shaft plastic shredder machine:
- Parameter technical:
| Model | Power(KW) | Number of revolving knife | Thickness of knife(mm) | Diameter of knife(mm) | Number of knife(mm) | Output(kg/hour) | |
| S2-600 | 11 | 12 | 50 | 280 | 5 | 300-800 | |
| S2-600 | 15 | 12 | 50 | 280 | 5 | 300-800 | |
| S2-800 | 22 | 16 | 50 | 300 | 5 | 500-1500 | |
| S2-800 | 37 | 16 | 50 | 300 | 5 | 500-1500 | |
| S2-1000 | 2*30 | 20 | 50 | 350 | 5 | 1000-2000 | |
| S2-1200 | 2*30 | 24 | 50 | 400 | 5 | 1500-2500 | |
| S2-1600 | 2*37 | 22 | 70 | 450 | 5 | 2000-3000 |
double shaft shredder machine
double shaft shredder machine
double shaft shredder machine
double shaft shredder machine
Certificate.
Shipping of the goods: plastic double shaft shredder
Trader Show PP PE film waste plastic recycle machine
If you want more informations, please contact with us directly.
Our company is near Shanghai ,about 130km.
TEL:0086-13921990308
ADR:Zhenbei road,leyu town,zhangjiagang city,jiangsu province,china
