Specifications
Trailor type water well drilling machine HF2001drilling angle 90-75
2electric motor Y160M 415kw 1440r/min
3economical
Trailor type water well drilling machine HF200
Application------ Trailor type Water Well Drilling machine HF200:
· This drill rig known to Portable Drilling Rig is widely used in coal mine, ore mine, stone quarry, energy industry and water well drilling.
· Our HF series drill rig are new generation products with full function for water well drilling, core drilling, geothermal well drilling and other geological exploration.
Description------ Trailor type Water Well Drilling machine HF200:
· Specially designed for water well drilling, core drilling, geothermal well drilling and other geological exploration.
· With inner mud pump or standard mud pump from 100L/min to 250L/min.
· Can supply various size accessories, like rod, bit, core barrel, rope, and so on.
Advantages------ Trailor type Water Well Drilling machine HF200:
1 Designed for both water well and core;
2 Suitable for different hardness of geological features;
3 Strong structure and scientific design enable them to drill water well deep and with large diameter;
4 Durable parts, long service life;
5 Easy operation and maintenance save extra costs;
6 Excellent quality with favorable prices;
7 Hydraulic type, no need of electric power when working in the open field.
Project case------ Trailor type Water Well Drilling machine HF200: · Our equipments have been exported to more than 100 countries all around the world and gain a good reputation both at home and abroad.
· We have established cooperation relationship with many universities to update technology and meet various needs from our customers.
Technical Parameters------Trailor Mounted Portable Water Well Drilling Rig:
HF200 unity machine parameter | ||
Drilling depth |
30--200m |
|
End hole caliber |
500-75mm |
|
Drill rod caliber |
50mm |
|
Drilling angle |
90°~75° |
|
Drill weight (No include power) |
910kg |
|
Unity machine dimensions |
2.5×1×1.3 2.5×0.9×1.3m |
|
Spindle | ||
spindle speed |
64,128,287,557r/min |
|
Spindle stroke |
450mm |
|
Hoist | ||
Max.single line hoisting capacity |
2000kg |
|
Single line lifting speed |
17,35,75,151r/min |
|
Tightrope caliber |
12.5mm |
|
Tightrope cubic measure |
35m |
|
Hug floodgate caliber |
254mm |
|
Hug folldgate belt width |
70mm |
|
Distance between drill and hole |
400mm |
|
Mud pump | ||
Type |
Horizontal single urn twin-action |
|
Displacement |
170L/min |
|
Diesle engine |
S1110 22HP |
|
Electric motor |
Y160M—4 15kw 1440r/min |
|
Maximum pressure |
1.5Mpa |
|
Work pressure |
0.7Mpa |
|
Water inlet caliber |
40mm |
|
Water to exit caliber |
30mm |
|
Triangle conveyer belt |
B1728mm |
|
