Help CenterRotary Trailer Type Drill Rig for Piling Foundation
Related Products
-
High Drilling Efficiency Hydraulic Rock Drilling Rig Mobile Drill RigUS$ 24,000 - 300,000MOQ: 1 Set -
Best Seller for One Year in Southeast Asia,High Quality Boring Machinery for Civil EngineeringHF100YUS$ 14,000 - 20,000MOQ: 1 Set
-
Hottest, Flexible and Durable! HF100 Grouting Hole Drill RigUS$ 13,500 - 16,500MOQ: 1 Set
-
Hottest, Flexible and Durable! HF100 Grouting Hole Drilling MachineUS$ 13,500 - 16,500MOQ: 1 Set
-
Hottest, Flexible and Durable! HF100 Grouting Hole DrillsUS$ 13,500 - 16,500MOQ: 1 Set
Specifications
it has the characteristics of compact structure, easy installation, stable performance, easy operation and maintainrotary trailer type drill rig for piling foundation
Features and advantages:
This machine is a trailer type machine. It has two tires with one axle under the chassis ,and it welds traction frame and
towing ring together. It can be dragged by one tractor.
This machine's work efficiency is high, drilling footage is speedy, assist time is short, especially suitable to
drill shallow well. This machine adopts color tower type combination, and It has drilling tools of motion link to
assure the upright of bore, it has the characteristics of compact structure, easy installation, stable performance,
easy operation and maintain, suitable to water well drilling and piling foundation.
Specification:
Max drilling diameter |
Drilling water well :100-600mm Piling :1200mm |
Max drilling depth |
180m |
Max output torque |
2knm |
Driving drilling pipe size |
108×4.5×6000mm |
Drilling pipe size |
108×4.5×4000mm |
Max drilling diamter of turntable |
140mm |
Turntable speed |
55R/min |
power |
7.5KW motor or 12HP diesel engine |
Hoist lifting capacity |
5T |
Overall Dimension |
4800×1700×6500mm |
Main machine Weight |
2200kg |
