Help CenterHF128A High Efficiency Hydraulic Rotary Drilling Rig Max Piling Depth 56m Piling Diameter 600-1600mm
Related Products
-
HF856A Efficiency Rotary Drilling Rig Rotary CE&ISO CertificationUS$ 12,100 - 15,000MOQ: 1 Set -
HF856A Rotary Piling Rig for Rode Bridge Foundation Construction With ISO & CE Certification 38tons Max Piling Depth 56mUS$ 12,100 - 15,000MOQ: 1 Set
-
HF168 Rotary Piling Machine 38 Tons Large Torque for Sale High Quality Big Torque 165KNmUS$ 12,100 - 15,000MOQ: 1 Set
-
HF-YD7 Functional Full Hydraulic Piling Driver With Hammer for Sale ISO & CE Certification Engineer Oversea Service okUS$ 50,000 - 80,000MOQ: 1 Set
-
HF168 Rotary Piling Machine Forfoundation Constructure Max Piling Depth 56mUS$ 12,100 - 15,000MOQ: 1 Set
HF-128 Rotary Drilling Rig
1.The folding mast structure has the advantages of simple, great durability, saving cost and making repair more convenient.
2.Using the high position-oriented structure for the frame, which guarantees the verticality between kelly bar and ground, kes constucture more convenient, improves work efficiency, increses safty.
3.Power head adopts unique patent structure, which save cost and make repair more convenient.
4.Main windlass: Adoption original imported hydraulic pressure motor from Italy. It has sensitivereaction and can free down, which speed can be up to 80m/min and improve the construction efficiency. Main winch lays in the cavit of te U-shape, whchlocates in the operator's right field of vision (enables operator to obseve working condition of main winch freely). This kind of situation is not only simple but also practical.
HF-128 Technical Data
Drilling diameter | mm | 600-1500 | |
Drilling depth | m | 42 | |
Overall measurement | Working dimentions | mm | 7630X3110X15592 |
Transport dimentions | mm | 15185X3110X3173 | |
Rotary drive torque | KNm | 50/102 | |
Rotation speed | rpm | 38/20 | |
Crowed clinder | Max. push | KN | 150 |
Max.pull | KN | 100 | |
Max. stroke | mm | 3000 | |
Main winch | Max. pull | KN | 120 |
Max. speed | m/min | 70 | |
Auxilary winch | Max. pull | KN | 60kn |
Max. speed | m/min | 50 | |
Engine | Rated speed | KW | 113 |
Type | B5.9-C Cummins U.S.A | ||
Electronic management system | Long distance monitor system | Available | |
Drilling record system | Available | ||
On car printer | Available | ||
Hydraulic system pressure | bar | 300bar | |
Chassis | Chassis modality | Available | |
Max.travel speed | km/h | 2.0km/h | |
Min. ground clearance | mm | 500 | |
Track width | mm | 800 | |
Mast inclination | Free adjustment forwares/backwares | 0-93° | |
Free adjustment left/right wards | +/-3° | ||
Machine weighth | kg | 36500 | |
1.Are you trading company or manufacturer?
We are professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2.Are your products qualified?
Yes, our products all have gained ISO certificate,and we have specialized quality inspection department for checking every machine before leaving our factory.
3.How about your machine quality?
All of our machines hold the ISO, QC and TUV certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.
4.Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your work site and provide the training for your staff.
5.What about the quality warranty?
We offer one-year quality warranty for machines' main body.
6.How long can you deliver the machine?
Generally, we can deliver the machine in 15-20 days.
